22 Parameter List

The parameter list is structured according to the menu branches of the control unit.
The parameters are listed in ascending numerical order. A headline (shaded) can
appear several times, i.e. a subject area may be listed at different places in the table.
For better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SETUP routine.
This parameter cannot be written when the frequency inverter is in operation.
I U
FIN, FIN,
(201)
value for ACU201 devices
(401)
value for ACU401 devices
ACU201 devices: U
At the control unit KP500 parameter numbers > 999 are displayed hexadecimal at the
leading digit (999, A00 ... B5 ... C66).
22.1

Actual Value Menu (VAL)

No.
210 Stator Frequency
211 R.m.s Current
212 Output Voltage
213 Active Power
214 Active Current
215 Isd
216 Isq
217 Encoder 1 Frequency
218 Encoder 1 Speed
221 Slip Frequency
222 DC-Link Voltage
223 Modulation
224 Torque
225 Rotor Flux
226 Winding Temperature
227 Act. Rotor Time Constant
228 Internal ref. frequency
229 Reference percentage
230 Actual percentage value
231 Peak value long-term Ixt
232 Peak value short-term Ixt
Operating Instructions ACU
06/13
P :
rated values of the frequency inverter, o: overload capacity of frequency inverter
FIN
=387,5 V, ACU401 devices: U
dmax
Actual Values of the Machine
Description
Actual Values of the Frequency Inverter
Actual Values of the Machine
Actual Values of the Frequency Inverter
Actual value memory
=770 V
dmax
Unit Display range
Hz 0.00 ... 999.99
A 0.0 ... I
max
V 0.0 ... U
FIN
kW 0.0 ... P
max
A 0.0 ... I
max
A 0.0 ... I
max
A 0.0 ... I
max
Hz 0.00 ... 999.99
1/min 0 ... 60000
Hz 0.0 ... 999.99
V 0.0 ... U -25
dmax
% 0 ... 100
Nm ± 9999.9
% 0 ... 100
deg.C 0 ... 999
ms 0 ... τ
max
Hz 0.00 ... f
max
% ± 300.00
± 300.00
%
% 0.00 ... 100.00
% 0.00 ... 100.00
Chapter
19.2
19.2
19.2
19.2
19.2
19.2
19.2
19.2
19.2
19.2
19.1
19.1
19.2
19.2
19.2
19.2
19.1
19.1
19.1
19.3
19.3
275
