5.5

ACU 401 (75.0 to 132.0 kW)

The frequency inverter is mounted in a vertical position on the assembly panel. The
following illustration shows the standard fitting.
The diameter of the fixing holes is 9 mm.
Assembly is done by screwing the back wall of the frequency inverter to the assembly
panel.
The dimensions of the device and the installation dimensions are those of the stand-
ard device without optional components and are given in millimeters.
ACU
401 75
06/13
Standard installation
x
300 mm
b
x
a
x
x
300 mm
a1
Dimensions [mm]
a b
132 kW
510 412
...
Operating Instructions ACU
c
c1
c2
c3
b1
b2
b3
Installation dimensions in mm
c a1 b1 b2
351 480 392 382
b3 c1 c2 c3
342 338 305 110
