Actual value memory

The assessment of the operating behavior and the maintenance of the frequency
inverter in the application are facilitated by storing various actual values. The actual
value memory guarantees monitoring of the individual variables for a definable peri-
od. The parameters of the actual value memory can be read out via a communication
interface and displayed via the operating unit. In addition, the operating unit provides
monitoring of the peak and mean values in the VAL menu branch.
No.
231 Peak Value Long Term Ixt
232 Peak Value Short Term Ixt
287 Peak value Vdc
288 Average value Vdc
289 Peak value heat sink temp.
Average value heat sink
290
temp.
291 Peak value inside temp.
292 Average value inside temp.
293 Peak value Iabs.
294 Average value Iabs
295 Peak value active power pos.
296 Peak value active power neg.
297 Average value active power
301 Energy positive
302 Energy negative
The actual values can be read out and monitored in the VAL menu branch of the oper-
ating unit. The parameter
selection of the actual value parameters to be selected.
Operating Instructions ACU
06/13
Actual value memory
Description
Utilization of the device-dependent overload of
60 seconds.
Utilization of the device-dependent overload of 1
second.
The maximum DC link voltage measured.
The mean DC link voltage calculated in the pe-
riod of observation.
The highest measured heat sink temperature of
the frequency inverter.
The mean heat sink temperature calculated in
the period of observation.
The maximum measured inside temperature in
the frequency inverter.
The mean inside temperature calculated in the
period of observation.
The highest abs. current calculated from the
measured motor phases.
The mean abs. current calculated in the period
of observation.
The largest calculated active power in motor op-
eration.
Maximum generator active power calculated
from the voltage, the current and the control
variables.
The mean active power calculated in the period
of observation.
The calculated energy to the motor in motor op-
eration.
The calculated energy from the motor in gen-
erator operation.
Operation level
Function
28 in the PARA menu branch defines the
261
