Code
F30 3n
F0A 10
F0B 13
F0C 40
In error occurrence the signal 162 - "Error Signal" is set. The signal can be linked
with inverter functions.
Output signals in error occurrence
Errors are indicated by digital signals.
162 -
Error Signal
3 -
1)
For linking with inverter functions
2)
For digital output
In addition to fault messages mentioned, there are further fault messages. However
these messages are only used for internal purposes and are not listed here. If you
receive fault messages which are not listed here, please contact the BONFIGLIOLI
customer service.
Please store the parameter file on your PC before contacting BONFIGLIOLI.
268
User Error VPLC
User triggered Error of Internal PLC. Please check the application man-
ual VPLC.
Optional Components
Data transmission from control unit KP 500 to the frequency inverter
not possible. At least one file must be stored in the control unit.
The communication module was fitted to slot B without disconnection
of the mains voltage, switch mains voltage off.
Internal monitoring
After 6 warm starts in less than 3 minutes this fault is triggered, due to
the expectation that a faulty programming of the PLC or the function
table is at hand. Additionally the PLC / Function table is stopped (P.
1399 = 0 only in RAM).
1)
Monitoring function signals an error which is displayed in
2)
parameter
Current Error
Operating Instructions ACU
Meaning
259.
