14.6.2 JOG frequency

The JOG function forms part of the functions for controlling the drive mechanism via
the control unit. Use the arrow keys to change the JOG frequency within the function.
The frequency of the output signal is set to the entered value if the FUN key is
pressed. The drive starts and the machine turns at the set
the JOG frequency has been changed using the arrow keys, this value is stored.
No. Description
489 JOG frequency

14.6.3 Fixed Percentages

The four percentage values define reference values which are selected via the
percent change-over 1
centage source
centage channel.
No. Description
520 Fixed percentage 1
521 Fixed percentage 2
522 Fixed percentage 3
523 Fixed percentage 4
By combining the logic states of the fixed percentage change-over modes 1 and 2,
fixed frequencies 1 through 4 can be selected:
Fixed percentage
change-over 1
0 = contact open
162
Parameter
75 and
Fixed percent change-over 2
476 defines the addition of the various sources in the reference per-
Parameter
Fixed Percentage Control
Fixed percentage
75
change-over 2
0 0
1 0
1 1
0 1
1 = contact closed
Operating Instructions ACU
Settings
Min. Max.
-999.99 Hz 999.99 Hz
Settings
Min.
-300.00 % 300.00 %
-300.00 % 300.00 %
-300.00 % 300.00 %
-300.00 % 300.00 %
Function / active fixed value
76
Fixed Percentage 1
Fixed Percentage 2
Fixed Percentage 3
Fixed Percentage 4
489. If
JOG frequency
Fact. sett.
5.00 Hz
Fixed
76. The
Reference per-
Max. Fact. sett.
0.00 %
20.00 %
50.00 %
100.00 %
520
521
522
523
