7.6

Reading Data from Control Unit

"Parameter transmission" enables the transmission of parameter values from the
control unit KP 500 to the frequency inverter. In this operation mode, all other func-
tions of the control unit are disabled, except for the COPY function. Transmission
from the frequency inverter to the control unit is also disabled.
Activation of the control unit KP 500 for parameter transfer is prepared via parameter
Program(ming)
inverter.
Program(ming)
Parameter
111 -
sion
110 - Standard operation
Parameter transmission mode can be activated on the control unit KP 500 only if at
least 1 file is stored in the control unit. Otherwise, the error message "F0A10" will be
displayed as soon as activation is attempted.

7.6.1 Activation

The control unit KP 500 can be configured both via the keys of the KP 500 and via
any available CM communication module. For configuration and activation of the
KP 500 control unit, proceed as follows:
Activation via keyboard of control unit
• In the parameter menu PARA, use the arrow keys to select parameter
gram(ming)
Use the arrow keys to set value 111 – Parameter transmission and confirm your
•
selection by pressing the ENT key.
Now the control unit is ready for activation.
Before data transmission, the control unit must be initialized:
• Unplug the control unit from the frequency inverter and connect again to the
same or another frequency inverter.
The initialization is started. During the time of initialization, init and a progress
indicator are displayed. After initialization, the control unit KP 500 is ready for
transfer of data to the frequency inverter.
Adjustment of parameter
can be undone via the control unit, provided that the control unit has not been initial-
ized yet.
In parameter
•
mal operation again and confirm by pressing the ENT key.
06/13
34. The control unit KP 500 must be connected to the frequency
34
Control unit P 500 is prepared for parameter trans-
transmis-
mission. A connected frequency inverter can receive
data from the control unit.
Resetting of control unit KP 500 to standard operation
mode.
34, and confirm your selection by pressing the ENT key.
Program(ming)
34, use the arrow keys to set the value 110 – Nor-
Program(ming)
Operating Instructions ACU
Function
34 to the value - Parameter transmission,
Pro-
95
