The parameter
change between the control via contacts or the control unit and/or the interface.
Local/Remote
0 - Control via Contacts
Control via state ma-
1 -
chine
Control via remote
2 -
contacts
Control via keypad,
3 - dir. of rot. via con-
tacts
Control via KP or
cont.,
4 -
dir. of rot. via con-
tacts
Control 3-wire, dir. of
5 -
rot. via contacts
Control via keypad,
13 -
dir. of rot. via keypad
Control via KP or
cont.,
14 -
dir. of rot. via con-
tacts
Control via cont.,
20 -
clockwise only
Control via keypad,
23 -
clockwise only
Control via cont. +KP,
24 -
clockwise rot. only
30 to 34
Control via KP,
43 - dir. of rot. via con-
tacts
Control via cont.+ KP,
44 - sense of rot. via cont.
+ KP
Control via 3-wire +
KP,
46 -
dir. of rot. via con-
tacts + KP
If the operation mode is changed while the drive is running, the drive will not be
stopped if no stop command is present in the new operation mode.
242
412 defines the operating behavior and enables a
Local/Remote
412
The Start and Stop commands as well as the direction
of rotation are controlled via digital signals.
The Start and Stop commands as well as the direction
of rotation are controlled via the DRIVECOM Statema-
chine of the communication interface.
The Start and Stop commands as well as the direction
of rotation are controlled via logic signals through the
communication protocol.
The Start and Stop commands are controlled from the
control unit and the direction of rotation is controlled
via digital signals.
The Start and Stop commands are controlled from the
control unit or via digital signals. The statement of the
direction of rotation only with the help of the digital
signals.
3-wire; control of direction of rotation and signal
87 via contacts.
control
The Start and Stop commands as well as the direction
of rotation are controlled via the control unit.
The Start and Stop commands are controlled from the
control unit or via digital signals. The statement of the
direction of rotation only with the help of the operating
unit.
The Start and Stop commands are controlled via digital
signals. Fixed direction of rotation, clockwise rotation
only.
The start and stop commands are controlled via key-
pad. Fixed direction of rotation, clockwise rotation only.
The Start and Stop commands are controlled from the
control unit or via digital signals. Fixed direction of rota-
tion, clockwise rotation only.
Operation mode 20 to 24, anticlockwise direction of
rotation only.
The start and stop commands are controlled via digital
signals. The statement of the direction of rotation
comes from the operating unit or via digital signals.
The Start and Stop commands as well as the sense of
rotation can be controlled from either the control unit
or via digital signals.
3-wire and control unit; control of direction of rotation
and signal
3-wire control
unit.
