Electronic Gear Via System Bus; Speed Sensor Simulation - BONFIGLIOLI ACTIVE CUBE Applications Manual

5
5.1
If the electronic gear is realized by means of the System Bus, the transmitted position
data must be converted in a pulse-width modulated repetition frequency signal. This is
done via the speed sensor simulation (remote encoder) which works as an internal
speed sensor. The type of evaluation is adjusted via parameter
Via parameter
generation of the signal for the speed sensor simulation is defined.
No.
499 Division Marks
Note: For the speed sensor simulation (remote encoder), the settings for
28
28

Electronic gear via System bus

Speed Sensor Simulation

Operation mode
0 - Off
1 - Single Evaluation
2 - Double Evaluation
4 - Quadruple Evaluation
Division Marks
Parameter
Description
Mode Division Marks
490 and
taken over.
Application Manual Electronic Gear
Application Manual Electronic Gear
Function
Speed measurement not active
Two-channel speed sensor with recognition of direction
of rotation via track signals A and B.
One signal edge is evaluated per division mark.
Two-channel speed sensor with recognition of direction
of rotation via track signals A and B.
Two signal edges are evaluated per division mark.
Two-channel speed sensor with recognition of direction
of rotation via track signals A and B.
Four signal edges are evaluated per division mark.
499, the number of division marks per revolution for
Min.
1
491 of the Master frequency inverter must be
Operation Mode
498.
Settings
Max. Fact. sett.
8192 1024
Operation
