BONFIGLIOLI ACTIVE Cube ACU 201-01 Operating Instructions Manual page 279

No.
237 Reset memory
369 Motor Type
370 Rated voltage
371 Rated current
372 Rated speed
373 No. of pole pairs
374 Rated cosine Phi
375 Rated frequency
376 Rated mech. power
377 Stator Resistance
378 Leakage Coefficient
383 Voltage constant
384 Stator Inductance
389 Factor Actual Value System
397 Nominal volumetric flow
398 Nominal pressure
400 Switching frequency
401 Min. switching frequency
405 Warning limit, short-term Ixt
406 Warning limit long-term Ixt
407 Warning Limit Heat Sink Temp
408 Warning Limit Inside Temp.
409 Controller status message
412 Local/Remote
415 IDC Compensation Limit
417 Frequency Switch-Off Limit
418 Minimum Frequency
419 Maximum Frequency
420 Acceleration (clockwise)
421 Deceleration (clockwise)
422 Acceleration anticlockwise
423 Deceleration anticlockwise
424 Emergency stop clockwise
425 Emergency stop anti-clockwise
426 Maximum leading
430 Ramp rise time clockwise
431 Ramp fall time clockwise
432 Ramp rise time anticlockwise
433 Ramp rise time anticlockwise
Operating Instructions ACU
06/13
Actual value memory
Description
Controlled commissioning
Rated Motor Parameters
Further motor parameters
System Data
Pulse Width Modulation
Error/warning behavior
Bus controller
Error/warning behavior
Frequency Limits
Frequency ramps
Unit Setting range
- Selection
- Selection
V 0.17⋅U ... 2⋅U
FIN
A 0.01⋅I ...10⋅o ⋅ I
FIN
U/min 96 ... 60000
- 1 ... 24
- 0.01 ... 1.00
Hz 10.00 ... 1000.00
kW 0.1⋅P ... 10⋅P
FIN FIN
mOhm 0 ... 65535
% 1.0 ... 20.0
mVmin 0.0 ... 850.0
mH 0.1 ... 500.0
- -100.000 ... 100.000
m3/h 1 ... 99999
kPa 0.1 ... 999.9
- Selection
- Selection
% 6 ... 100
% 6 ... 100
deg.C -25 ... 0
deg.C -25 ... 0
- Selection
- Selection
V 0.0 ... 1.5
Hz 0.00 ... 999.99
Hz 0.00 ... 999.99
Hz 0.00 ... 999.99
Hz/s 0.00 ... 9999.99
Hz/s 0.01 ... 9999.99
Hz/s -0.01 ... 9999.99
Hz/s -0.01 ... 9999.99
Hz/s 0.01 ... 9999.99
Hz/s 0.01 ... 9999.99
Hz 0.01 ... 999.99
ms 0 ... 65000
ms 0 ... 65000
ms 0 ... 65000
ms 0 ... 65000
Chapter
19.3
8.2.3
10.1
FIN
10.1
FIN
10.1
10.1
10.1
10.1
10.1
10.2.1
10.2.2
10.2.5
10.2.6
11.1
11.2
11.2
18.1
18.1
13.1
13.1
13.2
13.2
13.3
18.3
13.4
13.5
14.1
14.1
14.7
14.7
14.7
14.7
14.7
14.7
14.7
14.7
14.7
14.7
14.7
279
