ACU 201 (up to 3.0 kW) and 401 (up to 4.0 KW)

The frequency inverter is mounted in a vertical position on the assembly panel by
means of the standard fittings.
The following illustration shows the different mounting possibilities.
x
a
x
Assembly is affected by inserting the long side of the fixing plate in the heat sink and
screwing it to the mounting plate.
The dimensions of the device and the installation dimensions are those of the standard
device without optional components and are given in millimeters.
ACU
0.25 kW ... 1.1 kW
201
0.25 kW ... 1.5 kW
401
1.85 kW ... 4.0 kW
06/13
Standard installation
b
b1 b1
a1
a2
≥
x 100 mm
Dimensions [mm]
190
1.5 kW ... 3.0 kW
250
190
250
Operating Instructions ACU
c
c1
Installation dimensions [mm]
a b c a1
60 178 210 ... 230
60 178 270 ... 290
60 178 210 ... 230
60 178 270 ... 290
a2 b1 c1
260 30 133
315 30 133
260 30 133
315 30 133
