5.4

ACU 401 (37.0 to 65.0 kW)

The frequency inverter is mounted in a vertical position on the assembly panel by
means of the standard fittings. The following illustration shows the standard fitting.
x
a1
x
fixing braket top
(fixing with screws
Assembly is done by screwing the two fixing brackets to the heat sink of the frequen-
cy inverter and the assembly panel.
The frequency inverters are provided with fixing brackets, which are fitted using four
thread-cutting screws. The dimensions of the device and the installation dimensions
are those of the standard device without optional components and are given in milli-
meters.
ACU
401
46
Standard installation
b
b1
≥
x 100 mm
M5x20 )
Dimensions [mm]
a
37...65 kW 400
a a2
fixing braket bottom
(fixing with screws
Installation dimensions [mm]
b c a1
275 260 425 ... 445
Operating Instructions ACU
c
c1
M5x20 )
a2 b1 c1
470 20 160
06/13
