5.1.2.6

Speed sensor monitoring

In order to synchronize the machine orientation with the reference pulse, the speed sensor monitoring
operation mode
Operation Mode
In this setting, a wrong number of division marks is reported automatically and individual missing
division marks are corrected using the reference pulse.
Monitoring is turned off above the
Parameter
No. Identifier
760
Operation Mode
624
Frequency Limit
5.1.2.7 Speed control with two operating ranges
Operation with Speed Sensor 2 at low torsional frequencies enables higher amplification of the speed
controller for large inert tools.
In order to enable better adjustment of the properties of the speed controller at different speeds, it
can be divided in two operating ranges with different amplifications and integral times, independent of
the set actual speed source (see Chapter 5.1.2.5 "Actual speed source"):
− Amplification1/Integral Time1
− Amplification2/Integral Time2
The speed control changeover takes place at the torsional frequency set in Parameter
738.
Switch-Over Limit
• The value set in Parameter
than the
Frequency Limit
• Optimize
Amplification 1
• Optimize
Amplification 2
Parameter
No. Identifier
738
Speed Control Switch-Over Limit
721
Amplification 1
722
Integral Time 1
723
Amplification 2
724
Integral Time 2
11/13
760 must be set to "2 – Error" (default value).
624.
Frequency Limit
Unit
-
Hz
Speed Control Switch-Over Limit
624.
721 and
Integral Time 1
723 and
Integral Time 2
Unit
Hz
-
ms
-
ms
ACU
Spindle Applications
Setting range
0-off
2-Error
0.00 .. 999.99
738 should be at least 10% smaller
722 for operation with speed controller.
724 for sensor-less operation.
Setting range
0.00 .. 999.99
0.00 .. 500.00
0 .. 60000
0.00 .. 500.00
0 .. 60000
Default settings
2-Error
2.60
Speed Control
Default settings
55.00
5.00
91
5.00
182
33
