Acu 201 (4.0 To 9.2 Kw) And 401 (5.5 To 15.0 Kw) - BONFIGLIOLI ACTIVE Cube ACU 201-01 Operating Instructions Manual

5.2

ACU 201 (4.0 to 9.2 kW) and 401 (5.5 to 15.0 kW)

The frequency inverter is mounted in a vertical position on the assembly panel by
means of the standard fittings. The following illustration shows the standard fitting.
x
a1
x
fixing bracket top
(fixing with screws
fixing bracket bottom
(fixing with screws
Assembly is done by screwing the two fixing brackets to the heat sink of the frequen-
cy inverter and the assembly panel.
The frequency inverters are provided with fixing brackets, which are fitted using four
thread-cutting screws. The dimensions of the device and the installation dimensions
are those of the standard device without optional components and are given in milli-
meters.
ACU
201
401
44
Standard installation
b
b1
a a2
≥
x 100 mm
M4x20 )
M4x60 )
Dimensions [mm]
a
4.0 ... 5.5 kW
250
7.5 ... 9.2 kW 250
5.5 ... 9.2 kW 250
11.0 ... 15.0 kW
250
c
c1
Installation dimensions [mm]
b c a1
100 200 270 ... 290
125 200 270 ... 290
100 200 270 ... 290
125 200 270 ... 290
Operating Instructions ACU
a2 b1 c1
315 12 133
315 17.5 133
315 12 133
315 17.5 133
06/13
