8.4

Speed sensor

For some configurations an incremental speed sensor must be connected. Dependent
on the speed sensor type it can be connected to the basic device or to an expansion
module. Some applications require the connection to the basic device as well as to the
expansion module.
The source of the actual speed value is selected via parameter
766. By default, speed sensor 1 is used as the actual speed source. If speed
Source
sensor 2 of an expansion module delivers the actual value signal for the speed control-
ler, speed sensor 2 must be selected as the source.
Actual Speed Source
1 - Speed Sensor 1
2 - Speed Sensor 2
1)
Only available if an expansion module is installed.
Dependent on the application and applied speed sensors the settings of parameters
must be adapted according to the following table.
Parameter
490 Operation Mode
speed sensor 1
491 Division Marks
speed sensor 1
493 Operation Mode
speed sensor 2
494 Division Marks
speed sensor 2
495 Level
766 Actual Speed Source
X: can be set to any value, it is not evaluated
The above-mentioned parameters are selectable dependent on configuration setting
and installed expansion module.
Some applications require two speed sensors. Parameter
must be set to the motor speed sensor for motor control. The other speed sensor is
used external. Comply with the application manuals "Electronic gear" and "Positioning".
114
766
The actual speed source is speed sensor 1 of the
basic device (factory setting).
The actual speed source is speed sensor 2 of an
expansion module.
Only
speed sensor 1
> 0
1...8192
0 - Off
X
X
1
Operating Instructions ACU
Actual Speed
Function
1)
Only
speed sensor 2 speed sensors
0 - Off
X 1...8192
> 0
1...8192 1...8192
Selection Selection
2
Actual Speed Source
Both
> 0
> 0
1 or 2
766
