BONFIGLIOLI ACTIVE Cube ACU 201-01 Operating Instructions Manual page 219

No.
441 Fixed Frequency
442 Max. P-Component
443 Hysteresis
444 Amplification
445 Integral Time
446 Ind. Volume Flow Control Factor
618 Derivative Time
In modes 1,2,3 and 5, the output frequency is shifted along the ordinate axis to the
Minimum Frequency
corresponds to:
0 % =
Minimum Frequency
100 % =
The parameterization of the technology controller in the individual data sets enables
an adaptation to various operating points of the application with the data set change-
over via control contacts.
The technology controller operates in motor clockwise operation. The direction of rota-
tion can be changed via parameter
10.2.8 „Change sense of rotation".
Operating Instructions ACU
06/13
Parameter
Description
418. The percentage of the technology controller output value
418
419
Maximum Frequency
Settings
Min. Max.
-999.99 Hz +999.99 Hz
0.01 Hz 999.99 Hz
0.01 % 100.00 %
-15.00 +15.00
0 ms 32767 ms
0.10 2.00
0 ms 1000 ms
Change Sense of Rotation
Fact. sett.
0.00 Hz
50.00 Hz
10.00 %
1.00
200 ms
1.00
0 ms
1199. Refer to chapter
219
