8.5

Set-up via the Communication Interface

Parameter-setting and commissioning of the frequency inverter via one of the op-
tional communication interfaces include the plausibility check and the parameter
identification functions. The parameters can be adjusted by qualified users. The pa-
rameter selection during the guided commissioning procedure includes the basic pa-
rameters. These are based on standard applications of the corresponding configura-
tion and are therefore useful for commissioning.
WARNING
Parameter settings may only be changed by qualified staff. Before starting the
commissioning process, read the documentation carefully and comply with the safe-
ty instructions.
The parameter
ly after the selection (if controller enabling signal is present at digital inputs
S1IND/STOA and S7IND/STOB). The operation modes include functions which are
also carried out automatically one after the other during the guided commissioning
procedure.
SETUP Selection
0 - Clear Status
1 - Continue
2 - Abort
10 - Complete Setup, DS0
Auto set-up complete,
11 -
DS1
Auto set-up complete,
12 -
DS2
Auto set-up complete,
13 -
DS3
Auto set-up complete,
14 -
DS4
20 - Check Machine Data, DS0
Plaus. contr. motor data,
21 -
DS1
Plaus. contr. motor data,
22 -
DS2
Plaus. contr. motor data,
23 -
DS3
Plaus. contr. motor data,
24 -
DS4
Calculation and Para-
30 -
Ident., DS0
31 - Calc. and para ident., DS1
32 - Calc. and para ident., DS2
116
796 defines the function which is carried out direct-
SETUP Selection
796
The auto set-up routine does not perform a func-
tion.
The warning message is acknowledged and the
auto set-up routine is continued.
The auto set-up routine is stopped and a RESET of
the frequency inverter is performed.
The auto set-up routine is performed in data set 0
and the parameter values are stored in all of the
four data sets identically.
The parameter values of the auto set-up are stored
in data set 1.
The parameter values of the auto set-up are stored
in data set 2.
The parameter values of the auto set-up are stored
in data set 3.
The parameter values of the auto set-up are stored
in data set 4.
The auto set-up routine checks the rated motor
parameters in the four data sets.
The rated motor parameters in data set 1 are
checked for plausibility.
The rated motor parameters in data set 2 are
checked for plausibility.
The rated motor parameters in data set 3 are
checked for plausibility.
The rated motor parameters in data set 4 are
checked for plausibility.
The auto set-up routine determines extended mo-
tor data via the parameter identification feature,
calculates dependent parameters and stores the
parameter values in all of the four data sets identi-
cally.
Additional motor data are measured, dependent
parameters are calculated and the parameter val-
ues are saved in data set 1.
Additional motor data are measured, dependent
parameters are calculated and the parameter val-
ues are saved in data set 2.
