8.4.1 Speed sensor 1

Connect the speed sensor tracks to the digital inputs S5IND (track A), S4IND (track B)
and S6IND (track Z).
The speed sensor type and the evaluation required are adjusted via the
490 of speed sensor 1.
Mode
For a detailed description of possible settings refer to section 10.4.
No.
490 Operation Mode speed sensor 1
491 Division Marks speed sensor 1
Dependent on the
S5IND and S6IND are disabled for other functions. The functions will not be evaluated.
The actual speed and frequency of speed sensor 1 is displayed in Parameters 217 and
218.

8.4.2 Speed sensor 2

Speed sensor 2 must be connected to an expansion module. For connection, func-
tions and detailed parameter description refer to the applicable operation instructions
manual of the expansion module.
No.
493 Operation Mode speed sensor 2
494 Division Marks speed sensor 2
495 Level
The parameters 493, 494 and 495 are selectable dependent on the installed expan-
sion module.
Dependent on the
expansion module are disabled for other functions. The functions will not be evaluated.
The actual speed and frequency of speed sensor 2 is displayed in Parameters 219 and
220.
Operating Instructions ACU
06/13
Parameter
Description
490 of speed sensor 1 the digital inputs S4IND,
Operation Mode
Parameter
Description
493 of speed sensor 2 some digital inputs of the
Operation Mode
Settings
Min. Max.
Selection
1 8192
Settings
Min. Max.
Selection
1 8192
Selection
Operation
Fact.
1024
Fact.
1024
115
