BONFIGLIOLI ACTIVE Cube ACU 201-01 Operating Instructions Manual page 129

Operation mode
Single evaluation
1001 –
with reference track
Double evaluation
1002 –
with reference track
Quadruple evalua-
1004 – tion with reference
track
Single evaluation
with sense of rot.
1011 –
without sign with
ref. track
Double evaluation
with sense of rot.
1012 –
without sign with
ref. track
Single evaluation
sense of rot. via
1031 –
contact with ref.
track
Double evaluation
sense of rot. via
1032 –
contact with ref.
track
Single evaluation
1101 – inverted with refer-
ence track
Double evaluation
1102 – inverted with refer-
ence track
Quadruple evalua-
1104 – tion inverted with
reference track
Single evaluation
inv. with sense of
1111 –
rot. without sign
with ref. track
Double evaluation
inv. with sense of
1112 –
rot. without sign
with ref. track
Single evaluation
inv. sense of rot. via
1131 –
contact with ref.
track
Double evaluation
inv. sense of rot. via
1132 –
contact with ref.
track
Operating Instructions ACU
06/13
490
Two-channel speed sensor with recognition of direc-
tion of rotation via track signals A and B, reference
track via digital input S6IND. One signal edge is eval-
uated per division mark.
Two-channel speed sensor with recognition of direc-
tion of rotation via track signals A and B, reference
track via digital input S6IND. Two signal edges are
evaluated per division mark.
Two-channel speed sensor with recognition of direc-
tion of rotation via track signals A and B, reference
track via digital input S6IND. Four signal edges are
evaluated per division mark.
One-channel speed sensor via track signal A; the ac-
tual speed value is positive. The reference track is
connected to digital input S6IND. One signal edge is
evaluated per division mark. The digital input S4IND is
available for further functions.
One-channel speed sensor via track signal A; the ac-
tual speed value is positive. The reference track is
connected to digital input S6IND. Two signal edges
are evaluated per division mark. The digital input
S4IND is available for further functions.
One-channel speed sensor via track signal A. The
actual speed value is positive for signal "Low" and
negative for signal "High" at digital input S4IND. One
signal edge is evaluated per division mark. The refer-
ence track is connected to digital input S6IND.
One-channel speed sensor via track signal A. The
actual speed value is positive for signal "Low" and
negative for signal "High" at digital input S4IND. Two
signal edges are evaluated per division mark. The
reference track is connected to digital input S6IND.
Same as operation mode 1001. The actual speed val-
ue is negative.
Same as operation mode 1002. The actual speed val-
ue is negative.
Same as operation mode 1004. The actual speed val-
ue is negative.
Same as operation mode 1011. The actual speed val-
ue is negative.
Same as operation mode 1012. The actual speed val-
ue is negative.
One-channel speed sensor via track signal A. The
actual speed value is negative for signal "Low" and
positive for signal "High" at digital input S4IND. One
signal edge is evaluated per division mark. The refer-
ence track is connected to digital input S6IND.
One-channel speed sensor via track signal A. The
actual speed value is negative for signal "Low" and
positive for signal "High" at digital input S4IND. Two
signal edges are evaluated per division mark. The
reference track is connected to digital input S6IND.
Function
129
