15.3.9 Application warning mask
The Application Warning mask signals via a digital signal if an afore configured warn-
ing applies. The configuration of the Application Warning mask is carried out via
ate Appl. Warning Mask
As soon as limit switches are reached or contouring error limits are exceeded, a
warning can be issued. The warnings refer to the parameter values set in er-
ror/warning behavior. Depending on the application, any number of warnings can be
configured. This enables internal and/or external control using a common output
signal. The display of
Create Appl. Warning Mask
0 - no change
2 - Activate all Warnings
10 - Warning V-belt
Warning pos. SW-Limit-
11 -
Switch
Warning neg. SW-Limit-
12 -
Switch
Warning pos. HW-Limit-
13 -
Switch
Warning neg. HW-Limit-
14 -
Switch
15 - Warning Contouring Error
16 - Warning Encoder
17 - Warning User 1
18 - Warning User 2
102 - Deactivate all Warnings
110 - Deactivate Warning V-Belt
Deactivate Warning pos.
111 -
SW-Limit-Switch
Deactivate Warning neg.
112 -
SW-Limit-Switch
Deactivate Warning pos.
113 -
HW-Limit-Switch
Deactivate Warning neg.
114 -
HW-Limit-Switch
Deactivate Warning Contour-
115 -
ing Error
116 - Deactivate Warning Encoder Warning 16 is deactivated.
117 - Deactivate Warning User 1
118 - Deactivate Warning User 2
1)
Refer to the application manual "Positioning" for further details.
190
626.
Warning Application
626
The configured warning mask is not changed.
The warnings reports stated are linked in the
warning mask.
The
signals no-load operation of the application.
Warning message indicating that the positive
SW limit switch has been reached (parameter
1)
Positive SW limit switch
Warning message indicating that the negative
SW limit switch has been reached (parameter
1)
Negative SW limit switch
Warning message indicating that the positive
1)
HW limit switch has been reached.
Warning message indicating that the negative
1)
HW limit switch has been reached.
Warning message, indicating that the contour-
ing error monitoring range adjusted with pa-
1)
rameter
left.
An encoder with data track can trigger a warn-
ing. Selection is not effective with encoders
without data track.
The signal set on digital input
1363 is active.
The signal set on digital input
1364 is active.
All warnings are deactivated.
Warning 10 is deactivated.
Warning 11 is deactivated.
Warning 12 is deactivated.
Warning 13 is deactivated.
Warning 14 is deactivated.
Warning 15 is deactivated.
Warning 17 is deactivated.
Warning 18 is deactivated.
Operating Instructions ACU
273 is not affected by the Warning mask.
