BONFIGLIOLI ACTIVE Cube ACU 201-01 Operating Instructions Manual page 117

SETUP Selection
Calc. and para ident.,
33 -
DS3
Calc. and para ident.,
34 -
DS4
Para-Ident. Machine
40 -
Data only, DS0
Para-Ident. Machine
41 -
Data only, DS1
Para-Ident. Machine
42 -
Data only, DS2
Para-Ident. Machine
43 -
Data only, DS3
Para-Ident. Machine
44 -
Data only, DS4
Complete Setup w/o
110 -
Para-Ident., DS0
Complete Setup w/o
111 -
Para-Ident., DS1
Complete Setup w/o
112 -
Para-Ident., DS2
Complete Setup w/o
113 -
Para-Ident., DS3
Complete Setup w/o
114 -
Para-Ident., DS4
The "additional motor data" also contain values of the current controller settings.
The individual steps of the auto set-up routine can be monitored and checked via
parameter
continuously updates the status parameter which can be read out via the interface.
For the status message of the Auto set-up comply with
• Chapter 8.2.7 "Status messages during commissioning (SS...)"
• Chapter 8.2.8 "Warnings during commissioning (SA...)"
Chapter 8.2.9 "Error messages during commissioning (SF...)"
•
Operating Instructions ACU
06/13
796
Additional motor data are measured, dependent
parameters are calculated and the parameter val-
ues are saved in data set 3.
Additional motor data are measured, dependent
parameters are calculated and the parameter val-
ues are saved in data set 4.
Additional motor data are measured and saved in
all of the four data sets.
Additional motor data are measured and saved in
data set 1.
Additional motor data are measured and saved in
data set 2.
Additional motor data are measured and saved in
data set 3.
Additional motor data are measured and saved in
data set 4.
The auto set-up routine is performed in data set 0
and the parameter values are stored in all of the
four data sets identically. Extended motor data are
not measured.
The parameter values of the auto set-up are stored
in data set 1. Extended motor data are not meas-
ured.
The parameter values of the auto set-up are stored
in data set 2. Extended motor data are not meas-
ured.
The parameter values of the auto set-up are stored
in data set 3. Extended motor data are not meas-
ured.
The parameter values of the auto set-up are stored
in data set 4. Extended motor data are not meas-
ured.
797. The setup routine via the communication interface
SETUP Status
Function
117
