2 Parameter Description
[169] Auto mode
[180] Clock Fault
[181] Prev. Maintenance
2
[188] AHF Capacitor Connect
[189] External Fan Control
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve Control
[198] Drive Bypass
[199] Pipe Filling
[200] Full capacity
[201] Pump 1 running
[202] Pump 2 running
[203] Pump 3 running
[204] Pump 4 running
[205] Pump 5 running
[206] Pump 6 running
[207] Pump 7 running
[208] Pump 8 running
[209] Pump 9 running
5-33 Term X30/7 Digi Out (MCB 101)
Option:
[0] * No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Stand-by / no warning
[5] Running
[6] Running / no warning
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
86
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Output is high when the frequency converter is in Hand on mode (as indicated by the LED light
above [Auto]).
Function:
This parameter is active when option module MCB 101 is mounted in the frequency converter.
The control board receives supply voltage.
The frequency converter is ready for operation and applies a supply signal on the control board.
The frequency converter is ready for operation and is in Auto mode.
Ready for operation. No start or stop command is been given (start/disable). There are no warnings.
Motor is running.
Output speed is higher than the speed set in par. 1-81
motor is running and there are no warnings.
Motor runs at reference speed.
An alarm activates the output. There are no warnings.
An alarm or a warning activates the output.
The torque limit set in par. 4-16 Torque Limit Motor Mode
The motor current is outside the range set in par. 4-18
Motor current is lower than set in par. 4-50
MG.20.W1.22 - VLT is a registered Danfoss trademark
VLT Automation VT Drive FC322
Programming Guide
Min Speed for Function at Stop [RPM]
or par. 1-17 has been exceeded.
Current Limit .
Warning Current Low
.
. The
