2 Parameter Description
20-04 Feedback 2 Conversion
Option:
[0] *
Linear
2
[1]
Square root
20-06 Feedback 3 Source
Option:
[0] *
No function
[1]
Analog input 53
[2]
Analog input 54
[3]
Pulse input 29
[4]
Pulse input 33
[7]
Analog input X30/11
[8]
Analog input X30/12
[9]
Analog Input X42/1
[10]
Analog Input X42/3
[11]
Analog Input X42/5
[15]
Analog Input X48/2
[100]
Bus feedback 1
[101]
Bus feedback 2
[102]
Bus feedback 3
[200]
Ext. Closed Loop 1
[201]
Ext. Closed Loop 2
[202]
Ext. Closed Loop 3
20-07 Feedback 3 Conversion
Option:
[0] *
Linear
[1]
Square root
20-12 Reference/Feedback Unit
Option:
[0]
None
[1] *
%
[5]
PPM
[10]
1/min
[11]
RPM
[12]
Pulse/s
[20]
l/s
[21]
l/min
[22]
l/h
[23]
3
m
/s
188
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Function:
See par. 20-01
Feedback 1 Conversion
for details.
Function:
Feedback 1 Source
See par. 20-00
for details.
Function:
See par. 20-01
Feedback 1 Conversion
for details.
Function:
MG.20.W1.22 - VLT is a registered Danfoss trademark
VLT Automation VT Drive FC322
Programming Guide
