VLT Automation VT Drive FC322
Programming Guide
9-22 Telegram Selection
Option:
[1] Standard telegram 1
[100] * None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] * PPO 8
[200] Custom telegram 1
[202] Custom telegram 3
9-23 Parameters for Signals
Array [1000]
Option:
[0] * None
[302] Minimum Reference
[303] Maximum Reference
[341] Ramp 1 Ramp Up Time
[342] Ramp 1 Ramp Down Time
[351] Ramp 2 Ramp Up Time
[352] Ramp 2 Ramp Down Time
[380] Jog Ramp Time
[381] Quick Stop Ramp Time
[411] Motor Speed Low Limit [RPM]
[413] Motor Speed High Limit [RPM]
[416] Torque Limit Motor Mode
[417] Torque Limit Generator Mode
[590] Digital & Relay Bus Control
[593] Pulse Out #27 Bus Control
[595] Pulse Out #29 Bus Control
[597] Pulse Out #X30/6 Bus Control
[653] Terminal 42 Output Bus Control
[663] Terminal X30/8 Output Bus Control
[890] Bus Jog 1 Speed
[891] Bus Jog 2 Speed
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Function:
Select a standard Profibus telegram configuration for the frequency converter, as an alternative to
using the freely configurable telegrams in par. 9-15
Read Configuration .
Function:
This parameter contains a list of signals available for selection in par. 9-15
tion PCD Read Configuration
and par. 9-16
MG.20.W1.22 - VLT is a registered Danfoss trademark
2 Parameter Description
PCD Write Configuration
and par. 9-16
PCD Write Configura-
.
PCD
2
