Page 1 MAKING MODERN LIVING POSSIBLE Programming Guide VLT ® Automation VT Drive FC 322 Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 2 Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 3: Table Of Contents
Main menu – Water application – Group 29 Main Menu - Bypass Option - Group 31 3 Parameter Lists Parameter Options Default settings Operation/Display 0-** Load/Motor 1-** MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 4 Application Functions 22-** Timed Actions 23-** Cascade Controller 25-** Analog I/O Option MCB 109 26-** Cascade CTL Option 27-** Water Application Functions 29-** Bypass Option 31-** MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 5: How To Programme
This guide can be used with all FC 322 frequency converters with software version 1.7x or later. The actual software version number can be read from Software Version par. 15-43 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 6: How To Operate Graphical Lcp (Glcp)
It is possible to toggle between three status read-out displays by pressing the [Status] key. Operating variables with different formatting are shown in each status screen - see below. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 7 • Green LED/On: Control section is working. • Flashing Red LED/Alarm: Indicates an alarm. • Yellow LED/Warn.: Indicates a warning. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 8 VLT Automation VT Drive FC322 1 How to Programme Programming Guide Warn. Alarm MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 9 [Info] provides detailed information when needed. Exit Info mode by pressing either [Info], [Back], or [Cancel]. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 10 VLT Automation VT Drive FC322 1 How to Programme Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 11: Brakes 2
(trip). The key can be Enabled [1] or Disabled [0] via par. 0-43 Reset Keys on LCP MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 12 The parameter settings stored in the LCP are now transferred to the frequency converter indicated by the progress bar. When 100% is reached, press [OK]. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 13: Display Mode
Status screen III: This state displays the event and action of the Smart Logic Control. For further information, see section Smart Logic Control MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 14: How To Operate Numeric Lcp (Nlcp)
• Flashing red LED/Alarm: Indicates an alarm. Menu key [Menu] Select one of the following modes: • Status • Quick Setup • Main Menu MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 15 [Auto on] Key on LCP terminals and/or the bus, the frequency converter will start. The key can be [1] or [0] via par. 0-42 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 16: Parameter Set-Up
27 no connection to +24 V on terminal 27 is necessary to enable start. Coast Inverse (factory default value) is selected in Terminal 27, a connection to +24V is necessary to enable start. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 17 Illustration 1.9: Step 3: Use the up/down navigation keys to scroll down to Function Setups. Press [OK]. Illustration 1.10: Step 4: Function Setups choices appear. General Settings Choose 03-1 . Press [OK]. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 18 6-21 Terminal 54 High Voltage 6-24 Terminal 54 Low Ref/Feedb Value 6-25 Terminal 54 High Ref/Feedb Value 6-00 Live Zero Timeout Time 6-01 Live Zero Timeout Function MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 19: Reference / Ramps 3
After selecting a parameter group, choose a parameter by means of the navigation keys. The middle section on the GLCP display shows the parameter number and name as well as the selected parameter value. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 20 Place the cursor on the value to be saved and press [OK]. Illustration 1.18: Display example. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 21 [OK]. Change the value by using the up/down keys. Press [OK] to accept the new setting. Press [Cancel] to abort. Press [Back] to leave the parameter. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 22 Removes parameters selected in par. 25-00 Cascade Controller After initialization and power cycling, the display will not show any information until after a couple of minutes. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 23: Parameter Description
All digital input/output and analog input/output terminals are multifunctional. All terminals have factory default functions suitable for the majority of water applications but if other special functions are required, they must be programmed in parameter group 5 or 6. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 24: Main Menu - Operation And Display - Group
Part of Language package 1 [45] Romanian Part of Language package 1 [46] Magyar Part of Language package 1 [47] Czech Part of Language package 1 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 25 North America Sets par. 1-21 units to HP and the default value of par. 1-23 60 Hz. The setting not used is made invisible. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 26 (using the LCP [Hand On] button or Hand Start command via a digital input) the frequency converter restarts and operates at the retained speed reference. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 27 Parameters which are ‘not changeable during operation’ are marked FALSE in the parameter lists in Parameter Lists the section Factory setup Cannot be changed. It contains the Danfoss data set, and can be used as a data source when returning the other set-ups to a known state. Set-up 1 Set-up 4...
Page 28 , copy Set-up 1 to Set-up 2. Then set par. 0-12 This Set-up Linked to Set-up 2 [2]. This will start the linking process. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 29 , the LCP selected Set-up 1 and all others used the active set-up. 2.2.4 0-2* LCP Display Define the variables displayed in the Graphical Local Control Panel. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 30: Profibus 9
[1618] Motor Thermal Thermal load on the motor, calculated by the ETR function. See also parameter group 1-9* Motor Temperature. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 31 Fieldbus REF 1 Main reference value sent with control word via the serial communications network e.g. from the BMS, PLC or other master controller. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 32 Select a variable for display in line 1, right position. Display Line 1.1 Small [1614] * Motor Current The options are the same as those listed for par. 0-20 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 33 Motor Speed High Limit [Hz] and actual speed. The relation will depend on the type of unit selected in par. 0-30 Custom Readout Unit MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 34 [32] kg/h [33] t/min [34] [40] [41] m/min [45] [60] °C [70] mbar [71] [72] [73] [74] m WG [75] mm Hg [80] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 35 Use the buttons on the LCP to change a character. A character can be inserted by placing the cursor between two characters and pressing MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 36 0-65 Personal Menu Main Menu Password Password. Otherwise define the password in par. 0-60 0-60 Main Menu Pass- word. Hand Off/On Hand Off/On w. Passw. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 37 This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 38 Copies all parameters in the present Programming Set-up (defined in par. 0-11 ) to Set-up 4. Copy to all Copies the parameters in the present set-up over to each of the set-ups 1 to 4. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 39 All: Read only All: No access If par. 0-61 Access to Main Menu w/o Password is set to Full access [0], this parameter will be ignored. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 40 Choose how Daylight Saving Time/Summertime should be handled. For manual DST/Summertime enter the start date and end date in par. 0-76 DST/Summertime Start and par. 0-77 DST/Summer- time End [0] * Manual MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 41 Displays the current date and time. The date and time is updated continuously. The clock will not begin counting until a setting different from default has been made in par. 0-70 Date and Time MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 42: Main Menu - Load And Motor - Group
These settings will typically ensure optimum motor voltage but if the motor power factor cos phi requires tuning, an AMA function can be carried out using par. 1-29, MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 43 Motor Speed High Limit [RPM] Maximum Reference and par. 3-03 to the 87 Hz application. This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 44 . If motor rotation direction is incorrect, two motor phase cables should be interchanged. IMPORTANT: Mains power must be removed before disconnecting motor phase cables. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 45 The AMA sequence will adjust all motor parameters except the moment of inertia of the rotor and the iron loss resistance (par. 1-36 Iron Loss Resistance (Rfe) MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 46 This parameter cannot be adjusted while running. 1-36 Iron Loss Resistance (Rfe) Range: Function: Application [Application dependant] dependent* This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 47 1-23 Motor Frequency Motor Frequency par. 1-25 Motor Nominal Speed Motor Nominal Speed This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 48 This parameter is an array parameter [0-5] and is only accessible when par. 1-01 Principle is set to [0]. 1-56 V/f Characteristic - f Range: Function: Application [Application dependant] dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 49 0.25 kW - 7.5 kW < 10 Hz 11 kW - 45 kW < 5 Hz 55 kW - 550 kW < 3-4 Hz MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 50 [0.0 - 300.0 s] The function selected in par. 1-80 is active in the delay period. Enter the time delay required before commencing acceleration. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 51 1-81 Min Speed for Function at Stop [RPM] Range: Function: Function at Stop Application [0 - 600 RPM] Set the speed at which to activate par. 1-80 dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 52 ETR (Electronic Thermal Relay) functions 1-4 will calculate the load when set-up where they were selected is active. For example ETR-3 starts calculating when set-up 3 is selected. For the North American market: The ETR functions provide class 20 motor overload protection in accordance with NEC. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 53 Digital input 33 This parameter cannot be adjusted while the motor is running. Digital inputs should be set to “No operation” - see par. 5-1*. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 54: Main Menu - Brakes - Group
Set the duration of the DC braking current set in par. 2-01 , once activated. 2-03 DC Brake Cut In Speed [RPM] Range: Function: Application [Application dependant] dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 55 It is also possible to generate a warning via a relay/digital output. The measuring accuracy of the power monitoring depends on the accuracy of the resistance of the resistor (better than 20%). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 56 DC link caused by generative power from the load. Disabled No OVC required. [2] * Enabled Activates OVC. The ramp time is automatically adjusted to avoid tripping of the frequency converter. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 57: Main Menu - Reference/Ramps - Group
). When using preset references, select Pre- set ref. bit 0 / 1 / 2 [16], [17] or [18] for the corresponding digital inputs in parameter group 5-1* Digital Inputs. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 58 3-15 Reference 1 Source , par. 3-16 Reference 2 Source , par. 3-17 Reference 3 Source Control Source and par. 8-02 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 59: Ext. Closed Loop 21
Analog Input X42/3 [25] Analog Input X42/5 [29] Analog Input X48/2 [30] Ext. Closed Loop 1 [31] Ext. Closed Loop 2 [32] Ext. Closed Loop 3 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 60 [Application dependant] dependent* 2.5.3 3-4* Ramp 1 Configure the ramp parameter, ramping times, for each of the two ramps (par. 3-4* and par. 3-5*). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 61 3-52 Ramp 2 Ramp Down Time Range: Function: Application [Application dependant] dependent* 2.5.5 3-8* Other Ramps Configure parameters for special ramps e.g. Jog or Quick Stop. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 62 4-12 [Hz] , to Check Valve Ramp End Speed, set by the user in par. 3-86 or par. 3-87. When par. 3-85 is MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 63 [0 – Motor Speed Low Limit [Hz]] Set the speed in [Hz] below Motor Speed Low Limit where the Check Valve Ramp will no longer be active. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 64 Set the maximum permissible value for the resultant reference. This is advisable if the Digital Po- tentiometer is used for fine tuning of the resulting reference. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 65 Set the minimum permissible value for the resultant reference. This is advisable if the Digital Po- tentiometer is used for fine tuning of the resulting reference. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 66 VLT Automation VT Drive FC322 2 Parameter Description Programming Guide 3-95 Ramp Delay Range: Function: Application [Application dependant] dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 67: Main Menu - Limits/Warnings - Group
4-53 Warning Speed High to the same value as set Motor Speed High Limit [RPM] in par. 4-13 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 68 This absolute limit applies to all configurations and is inde- pendent of the setting in par. 1-00 Configuration Mode . This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 69 01 or 02. Programme the lower signal limit of the motor speed, n , within the normal working range of the frequency converter. Refer to the drawing in this section. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 70 No alarm is displayed if a missing motor phase occurs. [1] * Trip 100 ms An alarm is displayed if a missing motor phase occurs. [2] * Trip 1000 ms MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 71 VLT Automation VT Drive FC322 Programming Guide 2 Parameter Description This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 72 Semi-Auto Bypass Set-up will automatically reset to Off. The frequency Hand Auto On converter will stay in mode until are pressed on the LCP. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 73 4-64 Semi-Auto Bypass Set-up Option: Function: [0] * No function Enabled Starts the Semi-Automatic Bypass set-up and continue with the procedure described above. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 74: Main Menu - Digital In/Out - Group
Defines terminal 29 as a digital input. Output Defines terminal 29 as a digital output. This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 75 Pump 2 Interlock [131] Pump 3 Interlock [132] All = Terminals 18, 19, 27, 29, 32, X30/2, X30/3, X30/4. X30/ are the terminals on MCB 101. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 76 Enables a choice between one of the eight preset references according to the table below. [18] Preset ref bit 2 Enables a choice between one of the eight preset references according to the table below. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 77 , the function will be . If pressing the button on the LCP the motor will stop regardless of signals on Hand Start Auto Start MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 78 Controlled by RELAY8 Controlled by RELAY7 [138] Pump9 Interlock Controlled by RELAY9 Controlled by RELAY8 5-10 Terminal 18 Digital Input Option: Function: No operation Reset MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 79 [131] Pump 2 Interlock [132] Pump 3 Interlock [133] Pump 4 Interlock [134] Pump 5 Interlock [135] Pump 6 Interlock [136] Pump 7 Interlock MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 80 [22] Speed down [23] Set-up select bit 0 [24] Set-up select bit 1 [34] Ramp bit 0 [36] Mains failure inverse [51] Hand/Auto Start MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 81 This parameter is active when option module MCB 101 is installed in the frequency converter. It has the same options and functions as par. 5-1* except for Pulse input [32]. [0] * No operation MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 82 [35] External Interlock External Interlock function has been activated via one of the digital inputs. [40] Out of ref range [41] Below reference low MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 83 The input will go low whenever the Smart Logic Action [37] Set dig. out. A low is executed. [160] No alarm Output is high when no alarm is present. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 84 T ime The below setting options are all related to the Cascade Controller. Wiring diagrams and settings for parameter, see group 25-** for more details. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 85 Motor current is lower than set in par. 4-50 [14] Above current, high Motor current is higher than set in par. 4-51 Warning Current High MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 86 [64] Comparator 4 See par. group LC-1#. If Comparator 4 is evaluated as TRUE, the output will go high. Otherwise, it will be low. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 87 [Auto]), and no Stop or Start command is active. [168] Hand mode Output is high when the frequency converter is in Hand mode (as indicated by the LED light above [Hand]). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 88 The motor current is outside the range set in par. 4-18 Current Limit Warning Current Low [13] Below current, low Motor current is lower than set in par. 4-50 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 89 [64] Comparator 4 See par. group LC-1#. If Comparator 4 is evaluated as TRUE, the output will go high. Otherwise, it will be low. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 90 [Auto]), and no Stop or Start command is active. [168] Hand mode Output is high when the frequency converter is in Hand mode (as indicated by the LED light above [Hand]). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 91 Control Ready Drive Ready Drive Ready/Remote Stand-by/No Warning Running Running/No Warning Run on Ref./No Warning Alarm [10] Alarm or Warning [11] At Torque Limit MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 92 SL Digital Output B [82] SL Digital Output C [83] SL Digital Output D [84] SL Digital Output E [85] SL Digital Output F MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 93 [195] Bypass Valve Control [199] Pipe Filling [211] Cascade Pump1 [212] Cascade Pump2 [213] Cascade Pump3 [223] Alarm, Trip Locked [224] Bypass Mode Active MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 94 See par. 5-40 Function Relay If the selected Event condition changes before the on- or off delay timer expires, the relay output is unaffected. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 95 [0 - 110000 Hz] Enter the high frequency corresponding to the high motor shaft speed (i.e. high reference value) in Term. 33 High Ref./Feedb. Value par. 5-58 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 96 Options for readout output variables: [0] * No operation [45] Bus ctrl. [48] Bus ctrl., timeout [100] Output frequency [101] Reference [102] Feedback [103] Motor current MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 97 Set the maximum frequency for terminal 27, corresponding to the output variable selected in par. 5-60 Terminal 27 Pulse Output Variable This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 98 Set the maximum frequency for terminal 29 corresponding to the output variable set in par. 5-63 Terminal 29 Pulse Output Variable This parameter cannot be adjusted while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 99 This parameter holds the state of the digital outputs and relays that is controlled by bus. A logical '1' indicates that the output is high or active. A logical '0' indicates that the output is low or inactive. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 100 Contains the frequency to apply to the digital output terminal 6, when it is configured as [Bus Con- trolled Timeout] and time-out is detected. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 101: Main Menu - Analog In/Out - Group
6-00 Timeout Time , the function selected in par. 6-01 Live Zero Timeout Function will be activated. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 102 [4] overruled to max. speed • [5] overruled to stop with subsequent trip [0] * Freeze output Stop Jogging Max. speed Stop and trip MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 103 Enter the analog input scaling value that corresponds to the high voltage/high current value set in dependent* par. 6-11 Terminal 53 High Voltage and par. 6-13 Terminal 53 High Current MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 104 Enter the analog input scaling value that corresponds to the low voltage/low current value set in Terminal 54 Low Voltage Terminal 54 Low Current par. 6-20 and par. 6-22 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 105 X30/11. Term. X30/11 Filter Time Constant par. 6-36 cannot be changed while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 106 X30/12. par. 6-46 Term. X30/12 Filter Time Constant cannot be changed while the motor is running. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 107 : 0 - Torque limit (par. 4-16) [135] Torq.0-nom 4-20 mA : 0 - Motor rated torque [136] Power 4-20mA : 0 - Motor rated power MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 108 It is possible to get a value lower than 20 mA at full scale by programming values >100% by using a formula as follows: desired maximum current × 100 % . 10 × 100 % = 200 % MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 109 50% Terminal 42 Output Max Scale Output signal 20 mA is needed at 100% (75% of range) - set par. 6-52 to 75% MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 110 : 0 - Inverter Max. Current (par. 16-37 Inv. Max. Current ), (0-20 mA) [104] Torque 0-Tlim : 0 - Torque limit (par. 4-16 Torque Limit Motor Mode ), (0-20 mA) MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 111 6-62 if value is below 100%. This parameter is active when option module MCB 101 is mounted in the frequency converter. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 112 [0.00 - 100.00 %] Contains the value to apply to the output terminal, when it is configured as [Bus Controlled Timeout] and time-out is detected. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 113: Main Menu - Communications And Options - Group
Option Changed This parameter cannot be adjusted while the motor is running. None FC Port FC USB Option A Option B Option C0 Option C1 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 114 Reset Control Timeout toggles. Then the frequency converter resumes its original set-up. [1] * Resume set-up Resumes the set-up active prior to the time-out. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 115 “0” indicates T37 is low (safe stop) “1” indicates T37 is high (normal) 2.9.4 8-3* FC Port Settings Parameters for configuring the FC Port. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 116 No Parity, 2 Stop Bits 8-35 Minimum Response Delay Range: Function: Application [Application dependant] dependent* 8-36 Max Response Delay Range: Function: Application [Application dependant] dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 117 Activates Start command via the fieldbus/serial communication port OR via one of the digital inputs. Control Site Digital and control word This parameter is active only when par. 8-01 is set to [0] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 118 Activates Reverse command via the fieldbus/serial communication port OR via one of the digital inputs. Control Site Digital and control word This parameter is active only when par. 8-01 is set to [0] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 119 8-81 Bus Error Count Range: Function: [0 - 0 ] This parameter shows the number of telegrams with faults (e.g. CRC fault), detected on the bus. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 120 Range: Function: 200 RPM* [Application dependant] Enter the jog speed. This is a fixed jog speed activated via the serial port or fieldbus option. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 121 Bus Feedback 1 for further details. 8-96 Bus Feedback 3 Range: Function: Bus Feedback 1 [-200 - 200 ] See par. 8-94 for further details. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 122: Main Menu - Profibus - Group
FC Port CTW 1 [1686] FC Port REF 1 [2643] Terminal X42/7 Bus Control [2653] Terminal X42/9 Bus Control [2663] Terminal X42/11 Bus Control MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 123 [1653] Digi Pot Reference [1654] Feedback 1 [Unit] [1655] Feedback 2 [Unit] [1656] Feedback 3 [Unit] [1660] Digital Input [1661] Terminal 53 Switch Setting MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 124 , the hardware switch must be set to 126 or 127 (i.e. all switches set to ‘on’). Otherwise this parameter will display the actual setting of the switch. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 125 Pulse Out #X30/6 Bus Control [653] Terminal 42 Output Bus Control [663] Terminal X30/8 Output Bus Control [890] Bus Jog 1 Speed [891] Bus Jog 2 Speed MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 126 Analog Input 53 [1663] Terminal 54 Switch Setting [1664] Analog Input 54 [1665] Analog Output 42 [mA] [1666] Digital Output [bin] [1667] Pulse Input #29 [Hz] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 127 Parameters can be edited via Profibus, the standard RS485 interface, or the LCP. Disabled Disables editing via Profibus. [1] * Enabled Enables editing via Profibus. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 128 Enable cyclic master Enables process control via Profibus Master Class 1, and disables process control via standard field- bus or Profibus Master class 2. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 129 [0 - 0 ] This parameter contains the profile identification. Byte 1 contains the profile number and byte 2 the version number of the profile. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 130 VLT Automation VT Drive FC322 2 Parameter Description Programming Guide This parameter is not visible via LCP. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 131 Read only Range: Function: [0 - 9999 ] This parameter displays a list of all the defined frequency converter parameters available for Profi- bus. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 132 Read only Range: Function: [0 - 9999 ] This parameter displays a list of all the frequency converter parameters deviating from default set- ting. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 133 Read only Range: Function: [0 - 9999 ] This parameter displays a list of all the frequency converter parameters deviating from default set- ting. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 134: Main Menu - Can Fieldbus - Group
View the number of CAN control transmission errors since the last power-up. 10-06 Readout Receive Error Counter Range: Function: [0 - 255 ] View the number of CAN control receipt errors since the last power-up. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 135 Process Data Type Selection options [2] and [3] are available. Instances 100/150 and 101/151 are Danfoss-specific. Instances 20/70 and 21/71 are ODVA-specific AC Drive profiles. For guidelines in telegram selection, please refer to the DeviceNet Operating Instructions. Note that a change to this parameter will be executed immediately.
Page 136 Motor Current [1615] Frequency [%] [1616] Torque [Nm] [1617] Speed [RPM] [1618] Motor Thermal [1622] Torque [%] [1630] DC Link Voltage [1632] Brake Energy /s MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 137 Analog Input X42/3 [1832] Analog Input X42/5 [1833] Analog Out X42/7 [V] [1834] Analog Out X42/9 [V] [1835] Analog Out X42/11 [V] [1860] Digital Input 2 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 138 VLT Automation VT Drive FC322 2 Parameter Description Programming Guide [2795] Advanced Cascade Relay Output [bin] [2796] Extended Cascade Relay Output [bin] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 139 Enter the value for COS Filter 1 to set up the filter mask for the Status Word. When operating in COS (Change-Of-State), this function filters out bits in the Status Word that should not be sent if they change. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 140 10-33 Store Always Option: Function: [0] * Deactivates non-volatile storage of data. Stores parameter data received via DeviceNet in EEPROM non-volatile memory as default. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 141 No LCP access Range: Function: [0 - 0 ] This parameter is used to configure the frequency converter via DeviceNet and build the EDS-file. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 142: Main Menu - Smart Logic - Group
Enters the fixed value TRUE in the logic rule. Running See parameter group 5-3* for further description. In range See parameter group 5-3* for further description. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 143 Drive stopped This event is TRUE if the frequency converter is stopped or coasted by any means (either via digital input, fieldbus or other). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 144 See parameter group 5-3* for further description. [17] Mains out of range See parameter group 5-3* for further description. [18] Reversing See parameter group 5-3* for further description. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 145 Comparator 4 Use the result of comparator 4 in the logic rule. [51] Comparator 5 Use the result of comparator 5 in the logic rule. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 146 Motor voltage DC-link voltage Motor thermal [10] Drive thermal [11] Heat sink temp. [12] Analog input AI53 [13] Analog input AI54 [14] Analog input AIFB10 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 147 . Define the operators used to logically combine the selected inputs in par. 13-41 Logic Rule Operator 1 and par. 13-43 Logic Rule Operator MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 148 (TRUE / FALSE) of this calculation is combined with the settings of par. 13-43 and par. 13-44 , yielding the final result (TRUE / FALSE) of the logic rule. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 149 Use the result of timer 1 in the logic rule. [32] SL Time-out 2 Use the result of timer 2 in the logic rule. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 150 SL Time-out 7 Use the result of timer 7 in the logic rule. [80] No Flow [81] Dry Pump [82] End of Curve [83] Broken Belt MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 151 Out of feedb. range [14] Below feedb. low [15] Above feedb. high [16] Thermal warning [17] Mains out of range [18] Reversing [19] Warning [20] Alarm (trip) MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 152 SL Time-out 5 [73] SL Time-out 6 [74] SL Time-out 7 [80] No Flow [81] Dry Pump [82] End of Curve [83] Broken Belt MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 153 Out of feedb. range [14] Below feedb. low [15] Above feedb. high [16] Thermal warning [17] Mains out of range [18] Reversing [19] Warning MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 154 SL Time-out 5 [73] SL Time-out 6 [74] SL Time-out 7 [80] No Flow [81] Dry Pump [82] End of Curve [83] Broken Belt MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 155 [29] Logic rule 3 [30] SL Time-out 0 [31] SL Time-out 1 [32] SL Time-out 2 [33] Digital input DI18 [34] Digital input DI19 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 156 [10] Select preset ref 0 Selects preset reference 0. [11] Select preset ref 1 Selects preset reference 1. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 157 Starts timer 4, see par. 13-20 SL Controller Timer for further description. [72] Start Timer 5 Starts timer 5, see par. 13-20 SL Controller Timer for further description. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 158 Starts timer 6, see par. 13-20 for further description. [74] Start Timer 7 Starts timer 7, see par. 13-20 SL Controller Timer for further description. [80] Sleep Mode MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 159: Main Menu - Special Functions - Group
4.0 kHz [7] * 5.0 kHz 6.0 kHz 7.0 kHz [10] 8.0 kHz [11] 10.0 kHz [12] 12.0 kHz [13] 14.0 kHz [14] 16.0 kHz MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 160 [1] (no automatic energy optimization should be active). Illustration 2.2: Controlled Ramp-down - short mains failure. Ramping down to stop followed by ramping up to reference. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 161 [3] for derating the frequency converter. 2.13.4 14-2* Trip Reset Parameters for configuring auto reset handling, special trip handling and control card self test or initialisation. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 162 Enter the time interval from trip to start of the automatic reset function. This parameter is active Reset Mode Automatic reset when par. 14-20 is set to [1] - [13]. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 163 . The frequency converter will reset during the next power-up. par. 14-22 Operation Mode will also revert to the default setting Normal operation [0]. Boot mode MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 164 Controls the current limit control integration time. Setting it to a lower value makes it react faster. A setting too low leads to control instability. 14-32 Current Lim Ctrl, Filter Time Range: Function: 27.0 ms* [1.0 - 100.0 ms] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 165 RFI Filter circuit are cut off to avoid damage to the intermediate circuit and to reduce the earth capacity currents (according to IEC 61800-3). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 166 Derate [1]: If the critical temperature is exceeded the output current will be reduced until the al- lowable temperature has been reached. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 167 Defines the desired current level (in % of rated output current for the frequency converter) when running with reduced pump speed after load on the frequency converter has exceeded the allowable limit (110% for 60 sec.). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 168: Main Menu - Frequency Converter Information - Group
[1] and press [OK] to reset the kWh counter to zero (see par. 15-02 kWh Counter The reset is carried out by pressing [OK]. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 169 DC Link Voltage [1632] Brake Energy / s [1633] Brake Energy / 2 min [1634] Heatsink Temp. [1635] Thermal Drive Load [1650] External Reference MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 170 Samples Before Trigger (par. 15-14 [0] * False True Running In range On reference Torque limit Current limit Out of current range Below I low MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 171 Enter the percentage of all samples prior to a trigger event which are to be retained in the log. See Trigger Event Logging Mode also par. 15-12 and par. 15-13 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 172 View the time at which the logged event occurred. Time is measured in ms since frequency converter start. The max. value corresponds to approx. 24 days which means that the count will restart at zero after this time period. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 173 15-44 Ordered Typecode String Range: Function: [0 - 0 ] View the type code string used for re-ordering the frequency converter in its original configuration. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 174 [0 - 0 ] View the installed option type. 15-61 Option SW Version Range: Function: [0 - 0 ] View the installed option software version. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 175 0. Changes may not be visible until up to 30 seconds after implementation. 15-99 Parameter Metadata Array [23] Range: Function: [0 - 9999 ] This parameter contains data used by the MCT10 software tool. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 176: Main Menu - Data Readouts - Group
Readout Min Value Custom Readout Max Value tomReadou- ReadoutUnit] and par. 0-32 tUnit* 2.15.3 16-1* Motor Status Parameters for reading the motor status values. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 177 View the calculated thermal load on the motor. The cut-out limit is 100%. The basis for calculation is the ETRElectronic Thermal Overload function selected in par. 1-90 Motor Thermal Protection MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 178 The data are used for calculation of torque, motor protection, etc. 16-38 SL Controller State Range: Function: [0 - 100 ] View the state of the event under execution by the SL controller. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 179 The value is limited by settings in par. 20-13 and par. 20-14. Units as set in par. 20-12 Reference/ nit* Feedback Unit MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 180 . Units as set in par. 20-12 Reference/Feedback Unit 16-59 Adjusted Setpoint Option: Function: View value of the adjusted set point according to par.20-29. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 181 View the setting of input terminal 54. Current = 0; Voltage = 1. [0] * Current Voltage Pt 1000 [°C] Pt 1000 [°F] Ni 1000 [°C] Ni 1000 [°F] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 182 OptionB car d r ela y 07 P o w er car d r ela y 02 P o w er car d r ela y 01 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 183 View the two-byte word sent with the control word form the Bus-Master to set the reference value. For more information please refer to the relevant fieldbus manual. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 184 View the two-byte Status word (STW) sent to the Bus-Master. Interpretation of the Status word Control depends on the fieldbus option installed and the Control word profile selected in par. 8-10 Profile MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 185 Returns the extended warning word 2 sent via the serial communication port in hex code. 16-96 Maintenance Word Range: Function: [0 - 4294967295 ] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 186: Main Menu - Data Readouts 2 - Group
Read out of the value of the signal applied to terminal X42/3 on the Analog I/O Card. The units of the value shown in the LCP will correspond to the mode selected in par. 26-01 Terminal X42/3 Mode MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 187 Read out of the value of the signal applied to terminal X42/11 on the Analog I/O Card. Terminal X42/11 Output The value shown reflects the selection in par. 26-60 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 188: Main Menu - Fc Closed Loop - Group
Analog input X30/11 and Analog input X30/12 refer to inputs on the optional General Purpose I/O board. No function Analog input 53 [2] * Analog input 54 Pulse input 29 Pulse input 33 Analog input X30/11 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 189 Bus feedback 1 [101] Bus feedback 2 [102] Bus feedback 3 [200] Ext. Closed Loop 1 [201] Ext. Closed Loop 2 [202] Ext. Closed Loop 3 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 190 [0] * Linear Square root 20-12 Reference/Feedback Unit Option: Function: None [1] * [10] 1/min [11] [12] Pulse/s [20] [21] l/min [22] [23] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 191 This parameter determines the unit that is used for the setpoint reference and feedback that the PID Controller will use for controlling the output frequency of the frequency converter. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 192 Example 2 – Multi zone, multi setpoint MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 193 1 and Setpoint 1, Feedback 2 and Setpoint 2, and Feedback 3 and Setpoint 3. It will use the feed- back/setpoint pair in which the feedback is farthest above its corresponding setpoint reference. If MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 194 PID control adjustment. To use auto-tuning it is necessary for the frequency converter to be configured for closed loop in par. 1-00 Configuration Mode MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 195 Fast Pressure Slow Pressure Fast Temperature Slow Temperature 20-79 PID Autotuning Option: Function: Select the relative response speed for the application. [0] * Disabled Enabled MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 196 [1] causes the frequency converter’s output frequency to increase when the feedback is greater than the setpoint reference. 20-82 PID Start Speed [RPM] Range: Function: Application [Application dependant] dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 197 Max Reference Proportional Gain Maximum Reference/Feedb. Always set the desired for par. 20-14 before setting the values for the PID controller in par. group 20-9*. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 198 A smaller value reduces the maximum effect of the PID Controller’s differential function. PID Differentiation Time This parameter is only active when par. 20-95 is not set to OFF (0 s). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 199: Main Menu - Extended Closed Loop - Group
Excessive feedback sensor noise should be removed using the input filter (parameter groups 6-**,5-5* and 26-**, Terminal 53/54 Filter Time Constant/ Pulse Filter Time Constant #29/33) before activating PID autotuning. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 200 Normal setting of this parameter will be suitable for pressure control in fan systems. Fast Fast setting would generally be used in pumping systems, where a faster control response is de- sirable. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 201 21-10 Ext. 1 Ref./Feedback Unit Option: Function: Select the unit for the reference and feedback. [0] * [1] * [10] 1/min [11] [12] Pulse/s [20] [21] l/min [22] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 202 [131] lb/min [132] lb/h [140] ft/s [141] ft/min [145] [160] °F [170] [171] lb/in² [172] in WG [173] ft WG [174] in Hg [180] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 203 Analog Input X42/3 [25] Analog Input X42/5 [29] Analog Input X48/2 [30] Ext. Closed Loop 1 [31] Ext. Closed Loop 2 [32] Ext. Closed Loop 3 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 204 Readout of the output value for the Closed Loop 1 Controller. 2.18.4 21-2* Closed Loop 1 PID Configure the Closed Loop 1 PID controller. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 205 Configure Extended Closed Loop 2 Controller reference and feedback. 21-30 Ext. 2 Ref./Feedback Unit Option: Function: See par. 21-10 Ext. 1 Ref./Feedback Unit for details MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 206 [122] gal/min [123] gal/h [124] [125] ft³/s [126] ft³/min [127] ft³/h [130] lb/s [131] lb/min [132] lb/h [140] ft/s [141] ft/min [145] [160] °F MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 207 Analog Input X42/3 [25] Analog Input X42/5 [29] Analog Input X48/2 [30] Ext. Closed Loop 1 [31] Ext. Closed Loop 2 [32] Ext. Closed Loop 3 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 208 [0 - 100 %] See par. 21-19 Ext. 1 Output [%] for details. 2.18.6 21-4* Closed Loop 2 PID Configure the Closed Loop 2 PID Controller. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 209 [1] * [10] 1/min [11] [12] Pulse/s [20] [21] l/min [22] [23] m³/s [24] m³/min [25] m³/h [30] kg/s [31] kg/min [32] kg/h [33] t/min MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 210 21-52 Ext. 3 Maximum Reference Range: Function: Ext. 1 Maximum Reference 100.000 Ex- [Application dependant] See par. 21-12 for details. tPID3Unit* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 211 Ext. Closed Loop 3 21-55 Ext. 3 Setpoint Range: Function: Ext. 1 Setpoint 0.000 [-999999.999 - 999999.999 Ex- See par. 21-15 for details. tPID3Unit* tPID3Unit] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 212 21-64 Ext. 3 Dif. Gain Limit Range: Function: 5.0* [1.0 - 50.0 ] See par. 21-24 Ext. 1 Dif. Gain Limit for details. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 213: Main Menu - Application Functions - Group
Configuration mode for Integrated PI Controller: Closed Loop External PI Controller: Open Loop Carry out No Flow tuning before setting the PI controller parameters! MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 214 Possible Actions to select (par. 22-26): Warning Alarm No Flow Function No Power Tuning No Flow Detection must be enabled (par. 22-23, ) and commissioned (par. 22-3*, MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 215 Select Enabled for detecting when the motor operates with a speed as set in par. 4-11 Motor Speed Low Limit [RPM] Motor Speed Low Limit [Hz] or par. 4-12 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 216 22-20 Low Power Auto Set-up Close the main valve to stop flow Run with motor until the system has reached normal operating temperature MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 217 [Application dependant] dependent* 22-34 Low Speed Power [kW] Range: Function: Application [Application dependant] dependent* 22-35 Low Speed Power [HP] Range: Function: Application [Application dependant] dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 218 When entering Sleep Mode, the lower status line in the Local Control Panel shows Sleep Mode. See also signal flow chart in section 22-2* No Flow Detection There are three different ways of using the Sleep Mode function: MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 219 The feedback from the pressure transducer is monitored and when this pressure has dropped with a set percentage below the normal set point for pressure (Pset), the motor will ramp up again and pressure will be controlled for reaching the set value (Pset). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 220 The speed is set manually by an external reference signal (Remote Reference). The settings (par. 22-3*) for tuning of the No Flow function must be set to default. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 221 If used in application where the integrated PI controller is set for inverse control in par. 20-71, PID, Normal/Inverse Control , the value set in par. 22-44 will au- tomatically be added. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 222 End of Curve condition has been steady in the entire period, the function set in par. 22-50 End of Curve Function will be activated. If the condition disappears before the timer expires, the timer will be reset. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 223 The timer will start counting following a normal start command (Start/Jog/Freeze). The timer will be overridden by a Coast (Inverse) or an External Interlock command. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 224 Disabled [0] * Disabled : Set-Point compensation not active. Enabled Enabled :Set-Point compensation is active. Enabling this parameter allows the Flow Compensated Setpoint operation. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 225 Square-linear Curve Approximation Adjustment of par. 22-81 then allows the shape of the control curve to be adjusted infinitely. Example 2: MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 226 22-85 Speed at Design Point [RPM] Range: Function: Application [Application dependant] dependent* 22-86 Speed at Design Point [Hz] Range: Function: Application [Application dependant] dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 227 Function: 0.000* [0.000 - 999999.999 ] Enter the value corresponding to Flow at Rated Speed. This value can be defined using the pump datasheet. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 228: Main Menu - Time-Based Functions - Group
Select preset ref 4 [15] Select preset ref 5 [16] Select preset ref 6 [17] Select preset ref 7 [18] Select ramp 1 [19] Select ramp 2 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 229 Select the action during OFF Time. See par. 13-52 for descriptions of the op- tions. [0] * Disabled No action Select set-up 1 Select set-up 2 Select set-up 3 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 230 [61] Reset Counter B [70] Start Timer 3 [71] Start Timer 4 [72] Start Timer 5 [73] Start Timer 6 [74] Start Timer 7 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 231 Disabled [0]. Preventive Maintenance can be programmed from the LCP, but use of the PC-based VLT Motion Control Tool MCT10 is recommended. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 232 Pump bearings Valve Pressure transmitter Flow transmitter Temperature transm. Pump seals Fan belt [10] Filter [11] Drive cooling fan [12] System health check [13] Warranty MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 233 Maintenance Event will be indicated the following Monday at 8:00. If this Maintenance Event is not reset until Tuesday at 9:00, the next occurrence will be the following Tuesday at 9:00. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 234 (par. 15-06 All data for the Energy Log are stored in counters which can be read from par. 23-53 Energy Log MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 235 . In par. 0-79 Clock Fault it is possible to program for a Warning in case clock not has been set properly, e.g. after a power down. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 236 All counters are automatically reset when changing the setting in par. 23-50 Energy Log Resolution . At overflow the update of the counters will stop at maximum value. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 237 The size of each interval can be adjusted individually, but will default be 10% for each. Power and Current can exceed rated value, but those registrations will be included in 90%-100% (MAX) counter. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 238 Motor Speed [RPM] Speed of the motor. Reference for relative value is the maximum motor speed programmed in par. 4-13 Motor Speed High Limit [RPM] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 239 When mounting an Analog I/O MCB109 option card, a battery back up of the date and time is included. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 240 The difference between the Reference Power at fixed speed and the Actual Power yielded with speed control represent the actual saving. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 241 23-84 Cost Savings Range: Function: [0 - 2147483647 ] This parameter allows a readout of the calculation based on the above equation (in local currency). MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 242: Main Menu - Cascade Controller - Group
, all fixed speed pumps will be destaged, but the variable speed pump will still be controlled by the frequency converter, now as an open loop configuration: MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 243 [0]. Built-in relays Relay 1 and Relay 2 can be assigned to separate fixed speed pumps. In total three pumps can be controlled by the frequency converter. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 244 Setting the OBW too close to the SBW could defeat the purpose with frequent staging at momentary pressure changes. Setting the OBW too high might lead to unacceptably high or low pressure in the MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 245 If the pressure decreases to within the SBW before the timer has elapsed, the timer is reset. SB W destage dela y SB W S etpoin t SB W MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 246 , with at least one fixed speed pump in the stop position. When the programmed value of the timer expires, a fixed speed pump is staged. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 247 When the programmed value of the timer expires, a stage is removed, avoiding dead head water circulation in the adjustable speed pump. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 248 Soft Starter Motor Start Only to be used if [1] is selected in par. 25-02 25-42 Staging Threshold Range: Function: Application [Application dependant] dependent* MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 249 Staging Speed is calculated with the following formula: STAGE STAGE HIGH where n is Motor Speed High Limit and n is the value of Staging Threshold. HIGH STAGE100% MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 250 Destaging Speed is calculated with the following formula: DESTAGE DESTAGE HIGH where n is Motor Speed High Limit and n is the value of Destaging Threshold. HIGH DESTAGE100% MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 251 Alternation of the variable speed (lead) pump will take place at staging or the “At Command” signal. (See above.) It is not possible to select other than [0] if par. 25-05 Fixed Lead Pump is set to [1]. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 252 The lead pump function will be alternated only if the numbers of pumps running are providing less than 50% of total pump capacity. Lead Pump Alternation Only valid if par. 25-50 is different from [0]. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 253 , the illustration for description of staging and alternation. 2.21.6 25-8* Status Readout parameters informing about the operating status of the cascade controller and the pumps controlled. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 254 Relay ON time. 25-86 Reset Relay Counters Option: Function: Relay ON Time Resets all elements in par. 25-85 counters. [0] * Do not reset Do reset MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 255 If no lead pump is selected (Cascade Controller disabled or all pumps interlocked) the display will show NONE. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 256: Main Menu - Analog I/O Option Mcb 109 - Group
The Analog I/O option incorporates a real time clock with battery back-up. This can be used as back up of the clock function included in the frequency converter as standard. See section Clock Settings, parameter group 0-7*. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 257 Feedback Unit Ext. 3 Ref./Feedback Unit or par. 21-50 [1] * Voltage Pt 1000 [°C] Pt 1000 [°F] Ni 1000 [°C] Ni 1000 [°F] MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 258 I/O system, such as a Building Management System. Disabled MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 259 Enter the high voltage value. This analog input scaling value should correspond to the high refer- ence/feedback value set in par. 26-35 Term. X42/5 High Ref./Feedb. Value MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 260 I/O system, such as a Building Management System. Disabled [1] * Enabled MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 261 100 % desired maximum voltage i.e. × 100 % = 200 % Terminal 42 Output Max Scale See principle graph for par. 6-52 MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 262 25%. Scaling values up to 100% can never be higher than the corresponding setting in par. 26-52 Terminal X42/9 Max. Scale See principle graph for par. 6-51 Terminal 42 Output Min Scale MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 263 : 0 - 100%, (0-20 mA) [115] Ext. Closed Loop 3 : 0 - 100%, (0-20 mA) [139] Bus ctrl. : 0 - 100%, (0-20 mA) MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 264 VLT Automation VT Drive FC322 2 Parameter Description Programming Guide [141] Bus ctrl t.o. : 0 - 100%, (0-20 mA) MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 265 Holds the preset level of terminal X42/11. In case a bus time-out and a time-out function are selected, the output will preset to this level. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 266: Main Menu – Water Application – Group 29
29-04 until the filling set-point specified in par. 29-05 is reached. Illustration 2.9: Horizontal Pipe System Illustration 2.10: Vertical Pipe System MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 267 Specifies the Filled Set-point at which the Pipe Fill Function will be disabled and the PID controller will take control. This function can be used both for horizontal and vertical pipe systems. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com...
Page 268: Main Menu - Bypass Option - Group 31
15-07. The value is saved, when the frequency converter is turned off. 31-19 Remote Bypass Activation Option: Function: [0] * Disabled Enabled Feature: Unknown. MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 269: Parameter Lists
Unsigned 16 Uint16 Unsigned 32 Uint32 Visible String VisStr Normalized value 2 bytes Bit sequence of 16 boolean variables Time difference w/o date TimD MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 270 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 271 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 272 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 273 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 274 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 275 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 276 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 277 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 278 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 279 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 280 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 281 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 282 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 283 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 284 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 285 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 286 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 287 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 288 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 289 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 290 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 291 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 292 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 293 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 294 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 295 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 296 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 297 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 298 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 299 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 300 VLT Automation VT Drive FC322 3 Parameter Lists Programming Guide MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 301 VLT Automation VT Drive FC322 Programming Guide 3 Parameter Lists MG.20.W1.22 - VLT is a registered Danfoss trademark Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 302 Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 303 Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...
Page 304 130R0203 MG20W122 Rev. 2010-05-26 *MG20W122 Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx...

This manual is also suitable for:

Vlt dc 322

Danfoss VLT Automation VT Drive FC 322 Programming Manual

1 How to Programme

2 Parameter Description

3 Parameter Lists

Quick Links

Need help?

Questions and answers

Related Manuals for Danfoss VLT Automation VT Drive FC 322

Summary of Contents for Danfoss VLT Automation VT Drive FC 322

This manual is also suitable for:

Table of Contents
