2 Parameter Description
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
2
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
13-52 SL Controller Action
Array [20]
Option:
[0] * Disabled
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
154
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Function:
Select the action corresponding to the SLC event. Actions are executed when the corresponding
event (defined in par. 13-51 SL Controller Event
available for selection:
Changes the active set-up (par. 0-10 Active Set-up
Active Set-up
Changes the active set-up (par. 0-10
Changes the active set-up (par. 0-10 Active Set-up
Changes the active set-up (par. 0-10 Active Set-up
with other set-up commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 0.
Selects preset reference 1.
MG.20.W1.22 - VLT is a registered Danfoss trademark
VLT Automation VT Drive FC322
Programming Guide
) is evaluated as true. The following actions are
) to '1'.
) to '2'.
) to '3'.
) to '4'. If the set-up is changed, it will merge
