VLT Automation VT Drive FC322
Programming Guide
18-32 Analog Input X42/5
Range:
0.000* [-20.000 - 20.000 ]
18-33 Analog Out X42/7 [V]
Range:
0.000* [0.000 - 30.000 ]
18-34 Analog Out X42/9 [V]
Range:
0.000* [0.000 - 30.000 ]
18-35 Analog Out X42/11 [V]
Range:
0.000* [0.000 - 30.000 ]
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Function:
Read out of the value of the signal applied to terminal X42/5 on the Analog I/O Card.
The units of the value shown in the LCP will correspond to the mode selected in par. 26-02
X42/5 Mode .
Function:
Read out of the value of the signal applied to terminal X42/7 on the Analog I/O Card.
The value shown reflects the selection in par. 26-40
Function:
Read out of the value of the signal applied to terminal X42/9 on the Analog I/O Card.
The value shown reflects the selection in par. 26-50
Function:
Read out of the value of the signal applied to terminal X42/11 on the Analog I/O Card.
The value shown reflects the selection in par. 26-60
MG.20.W1.22 - VLT is a registered Danfoss trademark
2 Parameter Description
Terminal
Terminal X42/7 Output .
Terminal X42/9 Output
.
Terminal X42/11 Output
.
