Danfoss VLT Automation VT Drive FC 322 Programming Manual page 153

VLT Automation VT Drive FC322
Programming Guide
13-43 Logic Rule Operator 2
Array [6]
Option:
[0] * DISABLED
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
13-44 Logic Rule Boolean 3
Array [6]
Option:
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Function:
Select the second logical operator to be used on the boolean input calculated in par. 13-40
Rule Boolean 1 , par. 13-41 Logic Rule Operator 1
boolean input coming from par. 13-42
[13-44] signifies the boolean input of par. 13-44
[13-40/13-42] signifies the boolean input calculated in par. 13-40
par. 13-41 Logic Rule Operator 1 , and par. 13-42
setting). select this option to ignore par. 13-44
Function:
Select the third boolean (TRUE or FALSE) input for the selected logic rule.
See par. 13-40 Logic Rule Boolean 1
MG.20.W1.22 - VLT is a registered Danfoss trademark
2 Parameter Description
, and par. 13-42 Logic Rule Boolean 2
Logic Rule Boolean 2
.
Logic Rule Boolean 3 .
Logic Rule Boolean 1
Logic Rule Boolean 2 . DISABLED [0] (factory
Logic Rule Boolean 3
.
for further descriptions of choices and their functions.
Logic
, and the
2
,
151
