VLT Automation VT Drive FC322
Programming Guide
[0] *
Not linked
[1]
Set-up 1
[2]
Set-up 2
[3]
Set-up 3
[4]
Set-up 4
0-13 Readout: Linked Set-ups
Array [5]
Range:
0*
[0 - 255 ]
0-14 Readout: Prog. Set-ups / Channel
Range:
0*
[-2147483648 - 2147483647 ]
2.2.4 0-2* LCP Display
Define the variables displayed in the Graphical Local Control Panel.
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Readout: Linked Set-ups
After the link is complete, par. 0-13
changeable during operation' parameters are now the same in Set-up 1 and Set-up 2. If there are
changes to a 'not changeable during operation' parameter, e.g. par. 1-30
Set-up 2, they will also be changed automatically in Set-up 1. A switch between Set-up 1 and Set-
up 2 during operation is now possible.
Function:
View a list of all the set-ups linked by means of par. 0-12
one index for each parameter set-up. The parameter value displayed for each index represents
which setups are linked to that parameter setup.
Index
LCP value
0
{0}
1
{1,2}
2
{1,2}
3
{3}
4
{4}
Table 2.3: Example: Set-up 1 and Set-up 2 are linked
Function:
Programming Set-up
View the setting of par. 0-11
channels. When the number is displayed in hex, as it is in the LCP, each number represents one
channel.
Numbers 1-4 represent a set-up number; 'F' means factory setting; and 'A' means active set-up.
The channels are, from right to left: LCP, FC bus, USB, HPFB1.5.
Example: The number AAAAAA21h means that the FC bus selected Set-up 2 in par. 0-11
ming Set-up
, the LCP selected Set-up 1 and all others used the active set-up.
