0-23 Display Line 2 Large
Option:
[1615] * Frequency
0-24 Display Line 3 Large
Option:
[1652] * Feedback [Unit]
0-25 My Personal Menu
Range:
Application [0 - 9999 ]
dependent*
2.2.5 0-3*LCP Custom Readout
It is possible to customize the display elements for various purposes: *Custom Readout. Value proportional to speed (Linear, squared or cubed depending
on unit selected in par. 0-30
Custom Readout
The calculated value to be displayed is based on settings in par. 0-30
par. 0-32 Custom Readout Max Value
The relation will depend on the type of unit selected in par. 0-30
