2 Parameter Description

2.14 Main Menu - Data Readouts - Group 16

2.15.1 16-** Data Readouts
2
Parameter group for data read-outs, e.g. actual references, voltages, control, alarm, warning and status words.
2.15.2 16-0* General Status
Parameters for reading the general status, e.g. the calculated reference, the active control word, status.
16-00 Control Word
Range:
0* [0 - 65535 ]
16-01 Reference [Unit]
Range:
0.000 Ref- [-999999.000 - 999999.000 Refer-
erenceFeed- enceFeedbackUnit]
backUnit*
16-02 Reference [%]
Range:
0.0 %* [-200.0 - 200.0 %]
16-03 Status Word
Range:
0* [0 - 65535 ]
16-05 Main Actual Value [%]
Range:
0.00%* [-100.00% - 100.00%]
16-09 Custom Readout
Range:
0.00 Cus- [-999999.99 - 999999.99 Custom-
tomReadou- ReadoutUnit]
tUnit*
2.15.3 16-1* Motor Status
Parameters for reading the motor status values.
174
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Function:
View the Control word sent from the frequency converter via the serial communication port in hex
code.
Function:
View the present reference value applied on impulse or analog basis in the unit resulting from the
configuration selected in par. 1-00 Configuration Mode
Function:
View the total reference. The total reference is the sum of digital, analog, preset, bus, and freeze
references, plus catch-up and slow-down.
Function:
View the Status word sent from the frequency converter via the serial communication port in hex
code.
Function:
View the two-byte word sent with the Status word to the bus Master reporting the Main Actual Value.
Please refer to the Profibus Operating Instructions MG.33.CX.YY for a detailed description.
Function:
View the user-defined readouts as defined in par. 0-30
Readout Min Value Custom Readout Max Value
and par. 0-32
MG.20.W1.22 - VLT is a registered Danfoss trademark
VLT Automation VT Drive FC322
Programming Guide
(Hz, Nm or RPM).
Custom Readout Unit , par. 0-31 Custom
.
