VLT Automation VT Drive FC322
Programming Guide
10-13 Warning Parameter
Range:
0*
[0 - 65535 ]
Bit:
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
10-14 Net Reference
Read only from LCP
Option:
[0] *
Off
[1]
On
10-15 Net Control
Read only from LCP
Option:
[0] *
Off
[1]
On
2.11.4 10-2* COS Filters
Parameters for configuring COS filter settings.
10-20 COS Filter 1
Range:
0*
[0 - 65535 ]
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
Function:
View a DeviceNet-specific Warning word. One bit is assigned to every warning. Please refer to the
DeviceNet Operating Instructions (MG.33.DX.YY) for further information.
Meaning:
Bus not active
Explicit connection timeout
I/O connection
Retry limit reached
Actual is not updated
CAN bus off
I/O send error
Initialization error
No bus supply
Bus off
Error passive
Error warning
Duplicate MAC ID Error
RX queue overrun
TX queue overrun
CAN overrun
Function:
Select the reference source in Instance 21/71 and 20/70.
Enables reference via analog/digital inputs.
Enables reference via the fieldbus.
Function:
Select the control source in Instance 21/71 and 20/70.
Enables control via analog/digital inputs.
Enable control via the fieldbus.
Function:
Enter the value for COS Filter 1 to set up the filter mask for the Status Word. When operating in
COS (Change-Of-State), this function filters out bits in the Status Word that should not be sent if
they change.
MG.20.W1.22 - VLT is a registered Danfoss trademark
2 Parameter Description
2
137
