Danfoss VLT Automation VT Drive FC 322 Programming Manual page 144

2 Parameter Description
[41] Reset Trip
[42] Auto Reset Trip
2
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
13-02 Stop Event
Option:
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
142
Remote Site Products - 1-888-532-2706 - www.remotesiteproducts.com
http://www.remotesiteproducts.com/p-20772-Danfoss-131X8135-VLT-Automation-VT-Drive-VFD-FC322-230V-5-HP.aspx
This event is TRUE if the frequency converter is tripped (but not trip-locked) and the reset button
is pressed.
This event is TRUE if the frequency converter is tripped (but not trip-locked) and an Automatic Reset
is issued.
This event is TRUE if the OK key on the LCP is pressed.
This event is TRUE if the Reset key on the LCP is pressed.
This event is TRUE if the Left key on the LCP is pressed.
This event is TRUE if the Right key on the LCP is pressed.
This event is TRUE if the Up key on the LCP is pressed.
This event is TRUE if the Down key on the LCP is pressed.
Use the result of comparator 4 in the logic rule.
Use the result of comparator 5 in the logic rule.
Use the result of logic rule 4 in the logic rule.
Use the result of logic rule 5 in the logic rule.
Function:
Select the boolean (TRUE or FALSE) input to deactivate Smart Logic Control.
Enters the fixed value of FALSE in the logic rule.
Enters the fixed value TRUE in the logic rule.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
See parameter group 5-3* for further description.
MG.20.W1.22 - VLT is a registered Danfoss trademark
VLT Automation VT Drive FC322
Programming Guide
