PTO Speed Change
Transmission Model)
1. Disconnect the PTO speed change switch connector.
2. Measure the resistance between connector terminal as shown in
table below.
3. If the switch is defective, replace it.
When switch spring is
pushed (Neutral)
Resistance between
connector terminal
When switch spring is
Released
(1) PTO Speed Change Switch
Shuttle Switch Continuity (For Manual Transmission and GST
Model)
(Shuttle Switch)
1. Remove the steering post under cover.
2. Disconnected the shuttle switch connector (1).
3. Measure the resistance across four terminal referring to the table
below.
Shuttle lever
position
F N1
Forward
Neutral
Reverse
4. If 0 Ω is not indicated, the shuttle switch is faulty.
(Reference)
• There are only terminal N1 and COM1 for manual transmission
model.
(1) Shuttle Switch
9-S36
ELECTRICAL SYSTEM
Switch Continuity
0 Ω
Infinity
(2) Connector of Switch Side
Connector terminal
N2 R COM1 COM2
(2) Connector of Switch Side
(For Manual
W1042180
Resistance
0 Ω
W1044817
KiSC issued 02, 2007 A
