L3130 · L3430 · L3830 · L4630 · L5030, WSM
(B) Connector B (16P Connector) of Wire Harness Side
No.
M/T*
1
2
3
4
5
6 –
7
8
9
10 –
11
12
13
14
15
16
*M/T : Manual Transmission
Color of wiring
GST HST
Red
Black
Black / Yellow
Brown / White
Brown
Yellow
White
Yellow / Blue
Red / Blue
Red / Yellow
Black
Green / Red
–
Orange
Light Green
Green / Red
Disconnecting IntelliPanel Connector
1. Remove the combination switch (2).
2. Remove the panel cover (1).
3. Disconnect the panel connectors (5), (6).
4. Remove the IntelliPanel (3) from panel frame (4).
(1) Panel Cover
(2) Combination Switch
(3) IntelliPanel
M/T*
Check connector
Check connector
–
Coolant temperature sensor
–
Traveling speed sensor
Engine tachometer sensor
9-S23
ELECTRICAL SYSTEM
Terminal Name
GST HST
Power supply 12 V
GND (for circuit line)
GND (for sensor)
ECU (RS485 (+)) Check connector
ECU (RS485 (−)) Check connector
HST lever sensor
Fuel unit
Main switch ON
HST lever sensor
GND (for circuit line)
Parking brake switch
–
Lighting
(4) Panel Frame
(5) Connector A (20P)
(6) Connector B (16P)
KiSC issued 02, 2007 A
W1036395
