Error Display
Display on LCD
Screen
Selected Travel
Speed Is Not
Displayed on LCD
Trouble Item
(Affected Probable Cause
Model)
IntelliPanel • IntelliPanel memory
memory device device failure
has failed (All
model)
HST range • Lever sensor output
gear shift lever terminal is out of
sensor failure adjustment
(HST model) • Lever sensor wire
connector is broken or
short-circuited
• Lever sensor defective
NOTE:
ERROR-10 : is not
automatically displayed in
the LCD, but it is
memorized in the
IntelliPanel as error
information
Wrong setting • GST specified IntelliPanel
of IntelliPanel installed wrong on HST or
(Manual Manual transmission
Transmission model
and HST
model)
Communication • Fuse blown out
error between • Communication line
ECU and between ECU and
IntelliPanel IntelliPanel is broken or
(GST model) short-circuited
• No signals from ECU for
longer than 5 seconds
(error cleared if signal
sent and received later)
• ECU defective
ECU memory • ECU memory device
device has failure
failed (GST
model)
• Replace IntelliPanel
• Check lever sensor
wire connector
• Check sensor
voltage by Test
mode (Mode A)
• Check sensor
voltage by
connector
• Check sensor
resistance
• Replace lever
sensor
• Input appropriate
transmission model
by Transmission
model Input Mode
(Mode I)
• Check fuse
• Check ECU
connector
• Check
communication line
between ECU and
IntelliPanel at ECU
connector
• Replace ECU
• Replace ECU
9-S4
ELECTRICAL SYSTEM
Reference
Solution
Page
9-S23
9-S24
9-S13
9-S24
9-S26
9-S26
9-S19
9-S27
9-S27
9-S31
9-S28
9-S28
