(B) Attention Display (At Engine Starting)
If neither of the levers or pedals are in neutral positions when the main switch is turned to the "START" position,
the engine cannot be started. The IntelliPanel displays a message for the operator to correct the situation by placing
the appropriate lever or pedal in the neutral position.
Manual Transmission and GST Model
The safety switch for engine starting is adapted for the shuttle lever and the PTO shift lever in these models.
(Reference)
• As for the manual transmission model, selected speed displayed on left edge is not indicated.
When the shuttle lever is not set at a Neutral
position
Shift the shuttle lever to Neutral position.
When the PTO shift lever is not set at a Neutral
Position
Shift the PTO shift lever to Neutral position.
When both the shuttle lever and the PTO shift
lever are not set at a Neutral position
Shift both shuttle lever and PTO shift lever to Neutral
position.
9-M19
ELECTRICAL SYSTEM
W1017623
W1017667
W1017711
