wsm L503 Workshop Manual page 470

L3130 · L3430 · L3830 · L4630 · L5030, WSM
[5] COLOR OF WIRING
B ........... Black
G .......... Green
L ........... Blue
P ........... Pink
R ........... Red
V ........... Violet
W .......... White
Y .......... Yellow
Br .......... Brown
Lg .......... Light Green
Or .......... Orange
Sb ......... Sky Blue
B/G ......... Black / Green
B/L .......... Black / Blue
B/P .......... Black / Pink
B/Pu ........ Black / Purple
B/R .......... Black / Red
B/W ......... Black / White
B/Y ......... Black / Yellow
Br/B ........ Brown / Black
Br/Y ........ Brown / Yellow
G/B ......... Green / Black
G/L ......... Green / Blue
G/R ......... Green / Red
G/W ........ Green / White
G/Y ......... Green / Yellow
L/B .......... Blue / Black
L/G .......... Blue / Green
L/Or ......... Blue / Orange
L/R .......... Blue / Red
L/W ......... Blue / White
L/Y .......... Blue / Yellow
Lg/B ........ Light Green / Blue
Lg/W ....... Light Green / White
9-M6
Lg/Y ......... Light Green / Yellow
Or/W ......... Orange / White
R/B ............ Red / Black
R/G ............ Red / Green
R/L ............. Red / Blue
R/W ............ Red / White
R/Y ............. Red / Yellow
W/B ............ White / Black
W/G ........... White / Green
W/L ............ White / Blue
W/R ........... White / Red
W/Y ........... White / Yellow
Y/B ............ Yellow / Black
Y/G ............ Yellow / Green
Y/L ............. Yellow / Blue
Y/R ............. Yellow / Red
ELECTRICAL SYSTEM
W1019456
KiSC issued 02, 2007 A
