wsm L503 Workshop Manual page 16

L3130 · L3430 · L3830 · L4630 · L5030, WSM
[GST Type (with creep speed model)]
Model
Creep gear shift lever
Tire size (Rear)
Shuttle shift Main gear shift
lever lever
Forward
(At rated engine
rpm)
Reverse
(At rated engine
rpm)
The company reserves the right to change the specifications without notice.
[HST Type]
Tire size (Rear)
Shuttle shift lever
Forward
(At rated engine rpm)
Reverse
(At rated engine rpm)
The company reserves the right to change the specifications without notice.
High
km/h (mph)
1 1.68 (1.0)
2 2.38 (1.5)
3 3.07 (1.9)
4 3.86 (2.4)
5 4.54 (2.8)
6 5.71 (3.5)
7 6.75 (4.2)
8 8.49 (5.3)
9 9.55 (5.9)
10 12.01 (7.5)
11 19.49 (12.1)
12 28.78 (17.9)
1 1.40 (0.9)
2 1.98 (1.2)
3 3.22 (2.0)
4 4.76 (3.0)
5 7.07 (4.4)
6 10.01 (6.2)
7 16.24 (10.1)
8 23.99 (14.9)
Model
Range gear shift lever
L4630
Low
13.6-24
0.19 (0.1)
0.27 (0.2)
0.35 (0.2)
0.43 (0.3)
0.51 (0.3)
0.64 (0.4)
0.76 (0.5)
0.95 (0.6)
1.07 (0.7)
1.35 (0.8)
2.19 (1.4)
3.23 (2.0)
0.16 (0.1)
0.22 (0.1)
0.36 (0.2)
0.53 (0.3)
0.79 (0.5)
1.12 (0.7)
1.82 (1.1)
2.69 (1.7)
L
M
H
L
M
H
14
TRAVELLING SPEEDS
L5030
High Low
13.6-28
km/h (mph)
1.77 (1.1) 0.20 (0.1)
2.51 (1.6) 0.28 (0.2)
3.24 (2.0) 0.36 (0.2)
4.07 (2.5) 0.46 (0.3)
4.78 (3.0) 0.54 (0.3)
6.02 (3.7) 0.68 (0.4)
7.12 (4.4) 0.80 (0.5)
8.95 (5.6) 1.00 (0.6)
10.07 (6.3) 1.13 (0.7)
12.66 (7.9) 1.42 (0.9)
20.54 (12.8) 2.31 (1.4)
30.34 (18.9) 3.41 (2.1)
1.48 (0.9) 0.17 (0.1)
2.09 (1.3) 0.23 (0.1)
3.39 (2.1) 0.38 (0.2)
5.01 (3.1) 0.56 (0.3)
7.45 (4.6) 0.84 (0.5)
10.55 (6.6) 1.18 (0.7)
17.12(10.6) 1.92 (1.2)
25.28 (15.7) 2.84 (1.8)
L5030
14.9-26
km/h (mph)
0 to 6.10 (0 to 3.8)
0 to 11.80 (0 to 7.3)
0 to 28.60 (0 to 17.8)
0 to 5.50 (0 to 3.4)
0 to 10.60 (0 to 6.6)
0 to 25.70 (0 to 16.0)
W1032246
W1034865
KiSC issued 02, 2007 A
