wsm L503 Workshop Manual page 14

L3130 · L3430 · L3830 · L4630 · L5030, WSM
TRAVELLING SPEEDS
[Manual Transmission Type]
Tire size (Rear)
Shuttle shift Range gear shift
lever lever
Low
Forward
(At rated engine
rpm)
High
Low
Reverse
(At rated engine
rpm)
High
The company reserves the right to change the specifications without notice.
Model
Main gear shift
lever
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
L3130
12.4-24
km/h (mph)
1.81 (1.1)
2.56 (1.6)
4.16 (2.6)
6.14 (3.8)
9.13 (5.7)
12.91 (8.0)
20.96 (13.0)
30.96 (19.2)
1.51 (0.9)
2.13 (1.3)
3.46 (2.1)
5.11 (3.2)
7.61 (4.7)
10.76 (6.7)
17.47 (10.9)
25.80 (16.0)
12
TRAVELLING SPEEDS
L3830 - L4630
13.6-24
km/h (mph)
1.68 (1.0)
2.38 (1.5)
3.86 (2.4)
5.71 (3.5)
8.49 (5.3)
12.01 (7.5)
19.49 (12.1)
28.78 (17.9)
1.40 (0.9)
1.98 (1.2)
3.22 (2.0)
4.76 (3.0)
7.07 (4.4)
10.01 (6.2)
16.24 (10.1)
23.99 (14.9)
