wsm L503 Workshop Manual page 12

L3130 · L3430 · L3830 · L4630 · L5030, WSM
CABIN Type
Model
Model
Type
Number of cylinders
Total displacement
Bore and stroke
Net power
Engine
PTO power
(factory observe)
Maximum torque
Battery capacity
Fuel
Fuel tank
Engine crankcase
(with filter)
Capacities
Engine coolant
Transmission case
Overall length
(without 3P)
Overall width (min. tread)
Overall height
Dimensions
Wheel base
Min. ground clearance
Front
Tread
Rear
Weight
Front
Standard
tire size
Rear
Clutch
Steering
Travelling
system
Transmission
Braking system
Min. turning radius
(with brake)
Hydraulic control system
Pump capacity
Three point hitch
Hydraulic
system
At lift points
Max. lift
24 in. behind
force
lift points
System pressure
Rear PTO
PTO
PTO / Engine speed
Note : * Manufacture's estimate
The company reserves the right to change the specifications without notice.
L3830
Manual Transmission
D1803-MA-E-GST-EU
Indirect injection vertical, water-cooled, 4-cycle diesel
3
1.826 L (111.4 cu.in.)
87 × 102.4 mm (3.4 × 4.0 in.)
27.9 kW (37.9 HP)*
23.9 kW (32.5 HP)* /
−1
2700 min (rpm)
120.7 N·m
(12.3 kgf·m, 89.0 ft-lbs)
Diesel fuel No. 1 [below −10 °C (14 °F], Diesel fuel No. 2 [above −10 °C (14 °F)]
6.7 L (7.1 U.S.qts, 5.9 Imp.qts)
3075 mm (121.1 in.)
1840 mm (72.4 in.)
1140 mm (44.9 in.), 1210 mm (47.6 in.), 1310 mm (51.6 in.), 1410 mm (55.5 in.)
1640 kg (3616 lbs)
16 forward and 16 reverse speeds
31.5 L (8.3 U.S.gals, 6.9
Imp.gals) / min.
−1 −1
540 min (rpm) / 2550 min
−1
(rpm), 750 min (rpm) /
−1
2250 min (rpm)
10
L4630
V2203-MA-E-GST-EU
4
2.197 L (134.1 cu.in.)
87 × 92.4 mm (3.4 × 3.6 in.)
33.3 kW (45.3 HP)*
29.5 kW (40.1 HP)* / 2700 min
146.2 N·m (14.9 kgf·m, 107.8 ft-lbs)
12 V, RC : 133 min, CCA : 582 A
40 L (10.6 U.S.gals, 8.8 Imp.gals)
8.2 L (8.7 U.S.qts, 7.2 Imp.qts)
8.7 L (9.2 U.S.qts, 7.7 Imp.qts)
43 L (11.4 U.S.gals, 9.5 Imp.gals)
3170 mm (124.8 in.)
1485 mm (58.5 in.)
2195 mm (86.4 in.)
1895 mm (74.6 in.)
400 mm (15.7 in.)
1145 mm (45.1 in.)
1690 kg (3726 lbs)
8-16
13.6-24
Dry type single stage
Hydrostatic power steering
Wet disk type
2.7 m (8.9 feet)
Position control
37.0 L (9.8 U.S.gals, 8.1 Imp.gals) / min.
SAE Category 1
1750 kg (3860 lbs)
1250 kg (2760 lbs)
2
17.7 MPa (180 kgf/cm
, 2560 psi)
SAE 1-3/8, 6 splines
−1 −1
540 min (rpm) / 2550 min (rpm)
SPECIFICATIONS
GST
−1
(rpm)
24 forward and 16 reverse
speeds
