5.2.2

Configure the Terminal Emulator Program

On the User PC – Open the terminal emulator program, and then configure the program's serial
port communication and terminal display operation:
•
Baud Rate = 38400 bps
•
Data Bits = 8
•
Stop bits = 1
•
Parity = NO
•
Local Echo = ON
•
Port Flow Control = NONE
•
Display New Line Rx/Tx = CR
Read your terminal emulator program user guide or HELP feature for
operating and configuration instructions.
5.2.3

Get the Management IP Address and Firmware Information

Chapter 7. FRONT PANEL OPERATION
Chapter 9. BASE MODEM HTTP INTERFACE OPERATION
Chapter 10. SERIAL REMOTE CONTROL
Do these steps:
Step
1 On the modem – Apply power to the unit. Your power connection varies depending on your ordered
unit (i.e., AC vs. DC operation).
2
Identify your default Management IP Address. You will not be able to access the HTTP/HTTPS
(non-secure or secure Web Server) Interface without this information. See Section 5.2.3.1.
3 Get the firmware information using one of these methods:
Firmware Update
To use the modem Front Panel, see Section 5.2.3.2
•
To use the Serial Remote Interface, see Section 5.2.3.3
•
To use the HTTP/HTTPS Interfaces, see Section 5.2.3.4
•
Task
5–4
