Controller-to-Target
Instruction Code and
Qualifier
Parameter
Type
Command Query
Retrieve next 5 N/A RNA?
unread AUPC
Log Entries
AUPC Remote RCL= RCL?
Carrier Loss
Action
Remote Modem RPB= RPB?
Pattern
Substitution
Serial Remote Control
Arguments
for Command
(Note that all arguments are ASCII numeric codes from 48 to 57)
or Query
155 bytes Query only.
Returns the oldest 5 AUPC Log Entries that have not yet been read
over the remote interface in the form {CR}Sub-body{CR}Sub-
body{CR}Sub-body{CR} Sub-body{CR}Sub-body, where:
Sub-body = AA.ABB.BCCC.CEEE.Eddmmyyhhmmss:
AA.A = Minimum Eb/No during sample period.
BB.B = Average Eb/No during sample period.
CCC.C = Max Output Power during sample period.
EEE.E = Average Output Power during sample period.
ddmmyyhh = date in day/month/year format.
hhmmss = time in hours/minutes/seconds format.
Note: If there are less than 5 events to be retrieved, the remaining
positions are padded with zeros. If there are no new events, the
response is RNA*.
1 byte Command or Query.
Sets or returns Tx Output Power level setting, when remote carrier is
lost, in the form x, where:
0 = Hold current output power level
1 = Goto Nominal output power level
2 = Goto Maximum output power level
COMMAND EXAMPLE: <0001/RCL=0{CR}
1 byte Command or Query.
Sets or returns Remote Modem Tx Pattern Substitution in the form x,
where:
0 = Off
1 = On
Note: For compatibility reasons, only the 2047 Tx pattern can be
turned On or Off at the remote modem.
Example: <0001/RPB=1{CR} (Turns on remote modem AUPC
Control)
Description of Arguments
10–56
SLM-5650A Satellite Modem
Revision 10
Target-to-Controller
Response to Query
Response to
(see Description of
Command
Arguments)
N/A RNA=
{CR}AA.ABB.BCCC.C
EEE.Eddmmyyhhmms
s{CR}AA.ABB.BCCC.
CEEE.Eddmmyyhhmm
ss{CR}AA.ABB.BCCC.
CEEE.Eddmmyyhhmm
ss{CR}AA.ABB.BCCC.
CEEE.Eddmmyyhhmm
ss{CR}AA.ABB.BCCC.
CEEE.Eddmmyyhhmm
ss
RCL= RCL=x
RCL?
RCL*
RCL#
RPB= RPB=x
RPB?
RPB*
RPB#
