E.8.2.3 Satellite Modem Configuration (Modem Menu) (M)
The Modem Menu (Satellite Modem Configuration) page, opened from the Main Menu, contains the
following options/fields:
Menu
Options/Fields
Modem Type
Interface
Reference
Frequency Band
Modulator Settings
Demodulator Settings
Receive Monitor
Events
Stats
Utility
Appendix E
Entry
[RO] Displays modem type
[RO] Displays installed interface
[RO] Displays active reference (internal / external)
Prompts you to select:
B 0 – 70/140 MHz
1 – L-Band
M Allows you to configure modulator operating parameters
D Allows you to configure demodulator operating parameters
R Read-only – displays active Rx operating parameters
Displays the Modem Event Log and allows you to set or adjust display parameters
E
for logging
Displays the System Event Log and allows you to set or adjust display parameters
T
for logging
Allows you to select/set:
T – Time (in HH:MM:SS format)
U
D – Date (in DD/MM/YY format), or
C – Circuit ID (exactly 24 characters).
E–81
