E.8.2 Command Line Interface Pages
E.8.2.1 Main Menu
The Main Menu serves as the CLI's primary navigation page. All selections made on this page take
the user to submenus listed in this table (operation features nested under each of these submenus,
in turn, are described in the appendix sections listed):
Submenu
Administration
Satellite Modem
Configuration
LAN
WAN
Route Table
OSPF
IGMP
Vipersat
Configuration
Redundancy
Configuration
Appendix E
Entry Function/Description
The Administration Menu provides a basic set of
A
standard admin functions to the NP Interface.
The Satellite Modem Configuration option displays
nested menus that allow the user to configure and
M
monitor the satellite Base Modem.
The LAN menu allows the user to change the IP
address and view the ARP (Address Resolution
N
Protocol) table.
The WAN menu allows the user to configure QoS
W (Quality of Service) and DiffServ (Differentiated
Services).
The Route Table menu allows the user to configure the
R
Unicast/Multicast routing tables.
The OSPF Menu allows the user to configure Open
F
Shortest Path First routing parameters.
The IGMP Menu allows the user to configure Internet
I
Group Management Protocol parameters
The FAST-Feature-enabled Vipersat Configuration
menu allows the user to configure Vipersat functionality.
V
This menu selection is visible/available only after the
Vipersat option has been purchased.
The Redundancy Configuration Menu allows the user to
E
view the 1:1 IP redundancy status.
E–70
SLM-5650A Satellite Modem
Revision 10
Section
Sect. E.4.2.2
Sect. E.4.2.3
Sect. E.4.2.4
Sect. E.4.2.5
Sect. E.4.2.6
Sect. E.4.2.7
Sect. E.4.2.8
Sect. E.4.2.9
Sect. E.4.2.10
