Tx Collision Frames
The counters provided in this table are applicable in half-duplex only.
Column
Port
Collision
Late Collision
Single Collision
Multiple Collision
Maximum Collision
Tx Discarded/Filtered
Column
Port
Discarded
Filtered
Appendix E
This is the corresponding Ethernet port on the NP Interface and, when in BPM
Mode, the Base Modem's J5 Ethernet port.
This is the number of Collision events seen by the GMAC, not including those
controls in a single, Multiple, Excessive or Late.
This is the number of times a collision is detected later than 512 bits-times into
the transmission of the frame.
This is the total number of successfully transmitted frames that experienced
exactly one collision.
This is the total number of successfully transmitted frames that experienced
more than one collision.
This is the number of frames dropped in the transmit GMAC because the
frame experienced 16 consecutive collisions.
This is the corresponding Ethernet port on the NP Interface and, when in BPM Mode,
the Base Modem's J5 Ethernet port.
This is the total number of frames received with either FCS errors or Tx Maximum
Collision frames.
Currently not implemented.
