10.3.7 Automatic Uplink Power Control (AUPC) Commands and Queries
The instruction codes that follow are valid only when the SLM-5650A Satellite Modem Type has been set to AUPC.
Always wait three (3) seconds between consecutive remote modem command/query polls. If Local AUPC is not
enabled, queries will return the last known condition. A request for status from the remote modem will then be
transmitted, ensuring that the next query will return current status.
Controller-to-Target
Instruction Code and
Qualifier
Parameter
Type
Command Query
ASYNC ESC ACT= ACT?
Type
AUPC Eb/No AET= AET?
Target Set Point
AUPC Minimum AMN= AMN?
Power Level
AUPC AMT= AMT?
Maximum
Tracking Rate
Serial Remote Control
Arguments
for Command
(Note that all arguments are ASCII numeric codes from 48 to 57)
or Query
1 byte Command or Query.
Sets or returns ASYNC ESC Type in the form x, where:
0 = RS-232
1 = RS-485 2-Wire
2 = RS-485 4-Wire
Example: <0001/ACT=0{CR} (sets the ASYNC ESC to RS-232)
4 bytes Command or Query.
Sets or returns AUPC Eb/No Target in the form xx.x, where:
xx.x = value from 3.2 to 16.0 dB.
Example: <0001/AET=13.4{CR}
5 bytes Command or Query.
Sets or returns Minimum Tx Output power level in the form sxx.x,
where:
s = sign (+/–)
xx.x = value from –40.0 to +10.0 dBm.
Example: <0001/AMN=–13.4{CR}
3 bytes Command or Query.
Sets or returns AUPC Maximum Tracking Rate in the form x.x, where:
x.x = Maximum Tracking Rate, 0.5 to 6.0 dBm/minute in increments of
.5.
Example: <0001/AMT=0.5{CR}
Description of Arguments
10–51
SLM-5650A Satellite Modem
Revision 10
Target-to-Controller
Response to Query
Response to
(see Description of
Command
Arguments)
ACT= ACT=x
ACT?
ACT*
ACT#
AET= AET=xx.x
AET?
AET*
AET#
AMN= AMN=sxx.x
AMN?
AMN*
AMN#
AMT= AMT=x.x
AMT?
AMT*
AMT#
