H.3.3 BPM Mode in Hub Data Traffic Networks
1 TDM Modem
2 Hub LAN Data Switch
3 Hub router
4 Other Devices
5 Hub Demodulator Data Switch
6 Demodulator #1
7 Demodulator #2
8 Demodulator #N
Appendix I
Figure Legend
Equipment
A
B
C
D
E
F
G
Figure H-7. Hub Data Traffic Network
H–13
Data Type
STDMA Return Link
Forward Link
Network Encryption
MAC Learning Disabled (Entire Switch)
SCPC Return #1
SCPC Return #2
SCPC Return #N
SLM-5650A Satellite Modem
Revision 10
MN-SLM-5650A
