F.5.2 CLI Menu System – Parallel Functionality
Chapter 7. FRONT PANEL OPERATION
The CLI, accessible via SSH, allows you to change operating parameters in a manner similar to
the functionality as provided for the monitoring, configuration, and control via the SLM-5650A
Satellite Modem's front panel menus (see Chapter 7. FRONT PANEL OPERATION) and in the
TRANSEC Module HTTPS Interface (see Section F.2 in this appendix).
F.5.2.1 CLI Menu – Common Information, Navigation, Operation Features
With some exceptions, the menu pages depicted in this appendix feature the following common
informational or navigational aids:
Menu Options/Fields
[Text field example]
Logout of CLI Session
Exit Menu
Typically, once any mnemonic is entered, you are prompted to type in
a functional selection, an alphanumeric configuration string, or an
operational value. This prompt is provided at the bottom of the active
page and takes the form of a selection choice and/or a blank prompt
(a solid bar), as shown in the example to the right:
If a parameter is rejected for any reason, an error will appear at the top of the page, along with an
explanation that serves to assist you in the re-entry of information, as shown in these examples:
Appendix F
Entry
Typically found in the body of the page. This designates the field as a read-
only status/informational message. There is no user action required for this
[RO]
item.
Found at the bottom of the screen.
L
Allows user to log out of the CLI session.
Found at the bottom of the screen.
X
Allows user to exit the current menu and return to the parent menu.
Alternately, you may press the Esc key to perform the same action.
F–27
SLM-5650A Satellite Modem
Description
MN-SLM-5650A
Revision 10
