Receive Status
Item
RX CRC Errors
RX Frame Count
RX Status
DCM Lock
Unique Word Lock
Out of Sync
Automatic Refresh Status Timer
The page updates itself automatically for the duration of the countdown timer. When the timer
reaches 0:00, the page will stop updating to help conserve system resources.
To manually override the timer, click Stop to interrupt or Reset to restart the timer.
Appendix F
Displays the count of received CRC errors.
Displays the number of received AES 256 frames.
Displays the value of the Rx Status register.
Displays the state of the Rx DCM lock.
Indicates that the decryption engine has successfully found the unique word and has
been able to lock to it.
Indicates that an out-of-sync condition has been detected by the encryption engine.
