To prevent the display from becoming burnt by a constant image, the unit employs a screen saver

feature that activates after 15 minutes. This message constantly scrolls and wraps across the

screen. Sandwiched between the product display message "Comtech EF Data SLM-5650A

Modem" and the user prompt "Press any key to continue", the screen saver provides the following

operating statistics:

Modem Status Code

Press any key to exit the screen saver mode and restore the previously active screen.

Front Panel Operation

Circuit Identification

Demodulator receive frequency offset from the nominal

Buffer fill status (%)

Receive signal level (dBm)

Estimated Eb/No

Estimated Corrected Bit Error Rate

Bit Error Rate reported by the internal Bit Error Rate Test set

SLM-5650A Satellite Modem

MN-SLM-5650A
